10.3.1 Alarm troubleshooting table
Display
code
Log
code (*)
Description Checks
AtS 30 Restart in pump down Check cPt status (0=pump down at power up disabled)
cht 17 High pre-alarm condenser
temperature
Verify the status of the condensing unit, perform cleaning if necessary
CHt 18 High conductivity condenser
temperature
Verify the status of the condensing unit, perform cleaning if necessary
dA 14 Delayed alarm from external
contact
Check the status of digital input DI1 or DI2 - Remote delayed alarm
Detect anomaly on the external device connected to the digital inputs
Dor 15 Door open Check door opening and door sensor contact.
Check confi guration of "DIE" and "rIE" parameters
E1 1
Probe 1 faulty or disconnected
Check settings /P1 for probes S1 according
check probe is not broken and connected
E2 2
Probe 2 faulty or disconnected
Check settings /P2 for probes S2 according
check probe is not broken and connected
E3 3
Probe 3 faulty or disconnected
Check settings /P3 for probes S3 according
check probe is not broken and connected
E4 4
Probe 4 faulty or disconnected
Check settings /P4 for probes S4 according
check probe is not broken and connected
E5 5
Probe 5 faulty or disconnected
Check settings /P5 for probes S5 according
check probe is not broken and connected
Ed1 10 Defrost terminated
after maximum time
Check the evaporator status (correct fan operation, expansion valve opening).
Check the position of the defrost probe. It should be placed at the point on the evaporator where the
last part of the ice melts.
Check that the defrost duration is not too short (dP1) is too short
Check fan settings during defrost F3
Ed2 11 Defrost on second evaporator
terminated after maximum time
Check the status of the cabinet: correct operation of the fan, check the opening of the expansion valve.
Check defrost probe position: the probe must be positioned at the point of the evaporator where the last
part of the ice melts.
Check that the dP2 parameter has not been set too short.
Check the fan setting during defrost F3.
EHI 36 High temperature alarm
power supply
Check electrical connections
Check power voltage
ELO 37 Low pressure alarm
power supply
Check electrical connections
Check power voltage
Etc 9 Clock error Synchronize date and time with the device in use (PC or smartphone)
Upon completion of operations, perform a manual alarm reset to verify alarm reset
GHI 19
Generic alarm
high threshold
Check the settings of the generic alarm function and the threshold "GFA_Ht"
GLO 20
Generic alarm
low threshold
Check the settings of the generic alarm function and the threshold "GFA_Ht"
HA 21
Type HA HACCP alarm
(high temp. during operation)
Check the reading of the control probe and the thresholds "AH/AHA" "A1" "A0"
HF 22
Type HF HACCP alarm
(high temp. after blackout)
Check the reading of the control probe and the thresholds "AH/AHA" "A1" "A0"
HI 24
High temperature
Check the reading of the control probe and the thresholds "AH/AHA" "A1" "A0"
IA 13
Immediate alarm
from external contact
Check the status of digital input DI1 or DI2 - Remote alarm
Detect anomaly on the external device connected to the digital inputs
LO 23
Low temperature
Check the reading of the control probe and the thresholds "AL/ALA" "A1" "A0"
LP 32
Low pressure
check status of low pressure switch
PD 26
Maximum time
Pump down
Check c10 setting (pressure or time)
Check cPt: maximum time for pump down procedure to end
Check low pressure switch functionality"
rE 12
Control probe
faulty or disconnected
Verify parameter setting /4
if /4= 0, check air off temperature probe connection and status
if /4 = 100, check air on temperature probe connection and status
if /4 is between 1 and 99, check both probes"
rSF 31
Refrigerant leak alarm
Check the charghe of the circuit
After operations are completed, perform a manual alarm reset to verify alarm return
Src 35 Maintenance request check maintenance schedule
Tab. 10.c
