74
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Power supply / Relay outputs Isolation from very low voltages (digital/ana-
logue inputs, options)
reinforced / SELV
Isolation between independent relay
outputs
basic
Power supply
PROBES
5V 5 Vdc ± 2 % to power the 0 to 5 V ratiometric probes.
Maximum current delivered: 10 mA
Cable lengths Analogue inputs/outputs, digital inputs/out-
puts, probe power
< 10 m
BMS serial port (RS485): < 500 m with shielded cable
BMS serial (TTL) < 2 m
Conformity Electrical safety compliance -
LVD directive and UL certifi cation
IEC/EN/UL 60730-1, CSA E60730-1, IEC 60335-1 (sections 29 & 30)
Electromagnetic compatibility -
EMC directive
IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61000-6-4
For use with fl ammable refrigerants, the controllers described in this document have been tested and found to comply with the
following requirements of the IEC 60335 series standards:
• Annex CC of IEC 60335-2-24: 2010, referred to in clause 22.109, and Annex BB of IEC 60335-2-89: 2010, referred to
in clause 22.108; components that produce arcs or sparks during normal operation have been tested and found to
comply with the requirements of UL/IEC 60079-15;
• IEC/EN/UL 60335-2-24 (clauses 22.109, 22.110) for household refrigerators and freezers;
• IEC/EN/UL 60335-2-40 (clauses 22.116, 22.117) for electric heat pumps, air conditioners and dehumidifi ers;
• IEC/EN/UL 60335-2-89 (clauses 22.108, 22.109) for commercial refrigerating appliances.
Compliant for the following fl ammable refrigerants: Propane (R-290), ammonia (R-717), isobutane (R-600a), propylene (R-1270),
methane (R-50), n-butane (R-600), R-1234ze, R- 1234yf, R-32, R-455A, R-454B
The controllers have been verifi ed for the maximum temperatures of all components, which during the tests required by IEC
60335 cl. 11 and 19 do not exceed 272°C. The acceptability of these controllers in the fi nal application where fl ammable refrig-
erants are used needs to be reviewed and verifi ed depending on the fi nal application.
Wireless compliance RED directive (EN 301489-1), FCC (section 15, subsection B), IC.
Tab. 9.a
9.1 Connector/cable table
Ref. Description Wiring terminals Wire cross-section (mm
2
) Lmax (m)
L, N Controller power supply Removable screw terminal, 2-pin, pitch 5 mm
(Small without options)/5.08mm
(Small with options, Large)
0.05-3.3 (30-12 AWG) 10
S1 ... S3
(Small)
Probes Removable terminal;
5-pin, pitch 3.81 mm (Small, without options)
2x3 pins, pitch 3.5 mm (Small, with options)
4+3 pins, pitch 5.08 mm (Large)
0.05-1 (30-17 AWG) 10
S1 to S3, S4
(Large)
Probes Removable terminal;
5-pin, pitch 3.81 mm (Small, without options)
2x3 pins, pitch 3.5 mm (Small, with options)
4+3 pins, pitch 5.08 mm (Large)
0.05-3.3 (30-12 AWG) 10
S5, 5 V Probe power supply
ratiometric
Removable screw terminal, 2-pin, pitch 3.5 mm 0.05-1 (30-17 AWG) 10
DI1, DI2 Digital inputs Removable screw terminal, 5-pin, pitch 5.08 mm
(Small, without options)
2x3 pins, pitch 3.5 mm (Small, with options)
4+3 pins, pitch 5.08 mm (Large)
0.05-3.3 (30-12 AWG) 10
NO1...NO6 Digital outputs Removable terminal, 5-pin (Small), 4x3-pin
(Large), pitch 5.08 mm
0.05-3.3 (30-12 AWG) 10
BMS BMS serial port (RS485): Removable screw terminal, 3-pin, pitch 3.5 mm 0.05-1 (30-17 AWG) 500, with shielded cable, cross sec-
tion at least 0.33 mm
2
(22 AWG)
TTL BMS serial (TTL) JST ZH connector, 4-pin, pitch 2 mm
- Connection cable part number
(see “Introduction”).
0.03-13 (32-26 AWG) 2
Tab. 9.b
