71
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Code Description Def. Min Max UOM User User term.
rOk Auxiliary compressor without rotation digital output logic - see rOA 0 0 1 - S NO
rOn Pump down valve digital output logic - see rOA 0 0 1 - S NO
rOP Drain heater digital output logic - see rOA 0 0 1 - S NO
rOq Anti-sweat heater digital output logic - see rOA 0 0 1 - S NO
rOS Generic On/Off function digital output logic - see rOA 0 0 1 - S NO
rOt Condenser fan digital output logic - see rOA 0 0 1 - S NO
rOu Humidifi cation digital output logic - see rOA 0 0 1 - S NO
rOv Reverse digital output with dead band control logic - see rOA 0 0 1 - S NO
rOw Auxiliary parallel compressor digital output logic - see rOA 0 0 1 - S NO
rOx Gasket heater digital output logic - see rOA 0 0 1 - S NO
rOy Auxiliary compressor with rotation digital output logic - see rOA 0 0 1 - S NO
rOz External dehumidifi er digital output logic - see rOA 0 0 1 - S NO
rr Reverse output diff erential 2/ 3.6 0 20/ 36 Δ °C/°F S NO
rrH Dehumidifi cation diff erential 5 0 50.0 Δ % rH S NO
rSA Reset alarms 0 0 1 - U YES
rSC Restore default values 0 0 1 - S YES
Sc1 Custom temperature set point 1 0 r1 r2 °C/°F S NO
Sc2 Custom temperature set point 2 0 r1 r2 °C/°F S NO
Sc3 Custom temperature set point 3 0 r1 r2 °C/°F S NO
Sh1 Custom humidity set point 1 0 0 100 % rH S NO
Sh2 Custom humidity set point 2 0 0 100 % rH S NO
Sh3 Custom humidity set point 3 0 0 100 % rH S NO
St Temperature control set point 50/ 122 r1 r2 °C/°F U YES
St_Idx Custom set point index 0 0 3 - S NO
Sth Humidity control set point 90 0.0 100.0 % rH U YES
Strh Gasket heater control set point -18/ -0.4 -50/ -58 200/392 °C/°F S NO
td1..8-d Defrost 1 to 8 - day:
0 = event disabled; 1-7 = Monday to Sunday;
8 = Monday to Friday; 9 = Monday to Saturday;
10 = Saturday & Sunday; 11 = every day.
0 0 11 - U NO
td1..8-hh Defrost 1 to 8 - hours 0 0 23 hours U NO
td1..8-mm Defrost 1 to 8 - minutes 0 0 59 minutes U NO
td1..8-time Defrost 1 to 8 (Applica) 00:00:00 00:00:00 23:59:59 - U NO
TdL Diff erential to enable humidity control 0 0 20/ 36 Δ °C/°F U NO
tE1...8-d End time band 1 to 8 - day, see (td1...8-d) 0 0 11 - U NO
tE1...8-hh End time band 1 to 8 - hours 0 0 23 hours U NO
tE1...8-mm End time band 1 to 8 - minutes 0 0 59 minutes U NO
tE1...8-time End time band 1 to 8 (Applica) 00:00:00 00:00:00 23:59:59 - U NO
TestMode Enable test via BMS serial port 0 0 255 - (*) NO
THL Maximum temperature to enable humidity control 0 -60/ -76 60/ 140 °C/°F S NO
TLL Minimum temperature to enable humidity control 0 -60/ -76 60/ 140 °C/°F S NO
tS1...8-d Start time band 1 to 8 - day, see (td1...8-d) 0 0 11 - U NO
tS1...8-hh Start time band 1 to 8 - hours 0 0 23 hours U NO
tS1...8-mm Start time band 1 to 8 - minutes 0 0 59 minutes U NO
tS1...8-time Start time band 1 to 8 (Applica) 00:00:00 00:00:00 23:59:59 - U NO
ucd Compressor stop delay after HLVP protection activated 5 0 60 s S NO
udE Enable display of HLVP protection alarms
(EHI and ELO, see alarm table)
00 1 -SNO
uEn Enable HLVP protection: 0 = disabled; 1 = enabled. 0 0 1 - S NO
uHi High voltage protection start threshold 245 0 350 V S NO
uHo High voltage protection end threshold 255 0 350 V S NO
uLi Low voltage protection start threshold 205 0 350 V S NO
uLo Low voltage protection end threshold 195 0 350 V S NO
uof OFF time for humidity duty setting operation 60 c2 120 min S NO
uon ON time for humidity duty setting operation 10 c3 120 min S NO
Tab. 8.m
(*) Parameter only available via BMS serial.
(**) According to the selected confi guration and the wizard settings. See the list of available confi gurations in the Appendix.
8.2 Con guring the iJW controller via the Applica app
The “Applica” app can be used to confi gure the controller from a mobile device (smartphone, tablet), via NFC (Near Field Commu-
nication) or BLE (Bluetooth™ Low Energy). The app is used to confi gure the commissioning parameters and set groups of preset
parameters according to specifi c needs (confi gurations).
Procedure:
1. download the CAREL “Applica” app;
2. (on the mobile device) start the app for commissioning the controller;
3. enable NFC and/or BLE communication on the mobile device;
4. if using an NFC connection: tap the NFC icon and move the device near the controller to start reading the values. Both when
connecting to the device and when uploading the confi guration parameters, the mobile device must be less than 10 mm
from the controller;
5. if using a BLE connection:
– 1. tap the "BLUETOOTH" icon to view the iJM devices available within a range of 10 m.
– 2. select the device to connect to
