70
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Code Description Def. Min Max UOM User User term.
GFS_T Generic On/Off function, type: 0 = direct; 1 = reverse. 0 0 1 - S NO
H0 Serial address 1 1 247 - S YES
H10 BMS serial port baud rate (bit/s)
0 = 1200 3 = 9600 6 = 57600
1 = 2400 4 = 19200 7 = 115200
2 = 4800 5 = 38400
4 0 8 - S YES
H11 BMS serial port confi guration (stop bits and parity)
0 = 1 stop bit, no parity; 1 = 2 stop bits, no parity;
2 = 1 stop bit, even parity; 3 = 2 stop bits, even parity;
4 = 1 stop bit, odd parity; 5 = 2 stop bits, odd parity;
1 0 5 - S YES
H14 Time light stays on after closing the door 0 0 240 min U NO
H8 Output switched with time bands: 0 = Light; 1 = AUX. 0 0 1 - S NO
HA1, HA2, HA3 Activation date and time of the fi rst, second and third type HA alarm
(read-only)
-- - -UNO
HAn Number of type HA alarms (read-only) 0 0 6 - U YES
Hb Buzzer: 0 = disabled; 1 = enabled. 1 0 1 - U YES
Hdh Delta for anti-heating function 0 0 200/360 Δ °C/°F S NO
HF1, HF2, HF3 Activation date and time of the fi rst, second and third type HF alarm
(read-only)
-- - -UNO
HFn Number of type HF alarms (read-only) 0 0 6 - U YES
HMP Operating hour threshold for maintenance alarm hx1000 0 45 0 S NO
HMr Reset operating hours - 0 1 0 S NO
Htd HACCP alarm delay (0 = monitoring disabled) 0 0 240 min S NO
HU Humidity level: 0: low; 1: medium; 2: high. 1 0 2 - U YES
IS Working confi guration 0 0 IS_Max - S YES
IS_max Number of embedded confi gurations (read-only) 0 0 999 S NO
kbM Keypad operating mode: 0 = wake up; 1 = locked 0 0 1 - S NO
Lht Switch on light command 0 0 1 - U NO
MA1 Test mode, activate analogue output 1:
0 = disabled; 1 = automatic; 2 = activated at the value of MAr1.
00 1 -SNO
MA2 Test mode, activate analogue output 2 - see MA1 0 0 1 - S NO
MAr1 Test mode, analogue output 1 request 0 0 100 % S NO
MAr2 Test mode, analogue output 2 request 0 0 100 % S NO
Mr1 Test mode, activate relay1:
0 = disabled; 1 = automatic; 2 = activated.
10 2 -SNO
Mr2 Test mode, activate relay 2 - see Mr1 1 0 2 - S NO
Mr3 Test mode, activate relay 3 - see Mr1 1 0 2 - S NO
Mr4 Test mode, activate relay 4 - see Mr1 1 0 2 - S NO
Mr5 Test mode, activate relay 5 - see Mr1 1 0 2 - S NO
Mr6 Test mode, activate relay 6 - see Mr1 1 0 2 - S NO
Mt Manual mode duration (0 = manual mode always active) 10 0 90 min S NO
nFE Enable copy parameters from NFC memory to controller:
0 = copy parameters disabled; 1 = copy parameters enabled.
10 1 -SNO
OfT Gasket heater OFF time 3 0 250 min S NO
On On/Off command 0 = Off ; 1 = On. 0 1 - U YES (but-
ton)
OnT Gasket heater ON time 5 0 250 min S NO
PDS Service password 22 0 999 - S NO
r1 Minimum set point -50/ -58 -99/ - 146.2 r2 °C/°F S NO
r2 Maximum set point 50/ 122 r1 200/ 392 °C/°F S NO
r30 Control mode:
0 = direct with defrost; 1 = direct; 2 = reverse
00 2 -SNO
r4 Automatic night set point variation 3/5.4 -50/ -90 50/ 90 Δ °C/°F S NO
r4d Temperature control diff erential in ECO mode 4/ 7.2 0.1/ 0.2 99.9/179.2 Δ °C/°F S NO
r6a Control probe for night-time operation:
0 = virtual probe Sv; 1 = intake temperature probe Sr
00 1 -SNO
rAL Reset alarm log 0 0 1 - S YES
rd Temperature control diff erential 2/ 3.6 0.1/ 0.2 99.9/179.2 Δ °C/°F S YES
rdh Humidity control diff erential 5 0.1 99.9 % rH S YES
Rdrh Gasket heater control diff erential 2/ 3.6 0.1/ 0.2 20/ 36 Δ °C/°F S NO
rHP Reset HACCP event log 0 0 1 - U YES
rHt Anti-sweat heater or fan activation time
(0 = function disabled)
5 0 180 min S NO
rHU Anti-sweat heater or fan activation percentage
(0 = function disabled)
70 0 100 % S NO
rIA Immediate external alarm digital input logic:
0 = direct logic; 1 = reverse logic.
00 1 -SNO
rIb Delayed external alarm digital input logic
see DIA
00 1 -SNO
rIc Enable defrost digital input logic - see rIA 0 0 1 - S NO
rId Start defrost digital input logic - see rIA 0 0 1 - S NO
rIE Door switch with compressor OFF digital input logic - see rIA 0 0 1 - S NO
rIF Remote ON/OFF digital input logic - see rIA 0 0 1 - S NO
rIG Curtain switch digital input logic - see rIA 0 0 1 - S NO
Rih Start/stop continuous cycle digital input logic - see rIA 0 0 1 - S NO
rIo Working parameter set changeover digital input logic - see rIA 0 0 1 - S NO
rIP Door switch without compressor OFF digital input logic - see rIA 0 0 1 - S NO
rIS Generic function alarm digital input logic - see rIA 0 0 1 - S NO
rIt Low pressure switch digital input logic - see rIA 0 0 1 - S NO
rIU AUX output activation digital input logic - see rIA 0 0 1 - S NO
rn Dead band 4/ 7.2 0 60/ 108 Δ °C/°F S NO
rnH Dead band for humidity control 5 0 50.0 Δ % rH S NO
ro Control off set with probe error 0 0 20/ 36 Δ °C/°F S NO
rOA Compressor digital output logic:
0=direct; 1=reverse
00 1 -SNO
rOb Alarm digital output logic - see rOA 0 0 1 - S NO
rOc Auxiliary digital output logic - see rOA 0 0 1 - S NO
rOE Light digital output logic - see rOA 0 0 1 - S NO
rOG Defrost digital output logic - see rOA 0 0 1 - S NO
rOH Auxiliary evaporator defrost digital output logic - see rOA 0 0 1 - S NO
rOI Evaporator fan digital output logic - see rOA 0 0 1 - S NO
rOj Dehumidifi cation digital output logic - see rOA 0 0 1 - S NO
