iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Code Description Def. Min Max UOM User User term.
dP1 Maximum defrost duration 45 1 240 min S YES
dP2 Max auxiliary evaporator defrost duration 45 1 240 min S YES
dPH Defrost after opening the door: maximum defrost duration 15 dPL dP1 min S NO
dPL Defrost after opening the door: minimum defrost duration 5 0 dPH min S NO
dS1 Compressor off time in sequential stop defrost mode (0 = function dis-
abled)
0 0 45 min S NO
dS2 Compressor operating time in sequential stop defrost mode 120 0 240 min S NO
dt1 End defrost temperature (read by Sd) 4/39.2 -50/ -58 50/ 122 °C/°F S YES
dt2 Auxiliary evaporator end defrost temperature (read by Sd2) 4/39.2 -50/ -58 50/ 122 °C/°F S YES
F0 Evaporator fan management:
0 = always on;
1 = activation based on Sd – Sv;
2 = activation based on Sd; 3 = activation based on Sv.
00 3 -SNO
F00 Condenser fan management:
0 = always on with compressor on
1 = activation based on Sc, off with compressor off .
00 1 -SNO
F1 Evaporator fan activation threshold (only if F0 = 1, 2, 3) 5/ 41 -50/ -58 50/ 122 °C/°F S NO
F10 Evaporator fan forcing time at maximum speed
(0 = function disabled)
0 0 240 min S NO
F11 Fan ON time with low humidity level 60 0 600 s S NO
F12 Fan OFF time with low humidity level 120 0 600 s S NO
F13 Fan ON time with medium humidity level 120 0 600 s S NO
F14 Fan OFF time with medium humidity level 120 0 600 s S NO
F15 Fan ON time with high humidity level 180 0 600 s S NO
F16 Fan OFF time with medium humidity level 120 0 600 s S NO
F17 Temperature control diff erential for compressor activation with low hu-
midity level
2.0/ 3.6 0.1/ 0.2 20/ 36 Δ °C/ °F S NO
F18 Temperature control diff erential for compressor activation with medium
humidity level
2.0/ 3.6 0.1/ 0.2 20/ 36 Δ °C/ °F S NO
F19 Temperature control diff erential for compressor activation with high
humidity level
2.0/ 3.6 0.1/ 0.2 20/ 36 Δ °C/ °F S NO
F2 Evaporator fans with compressor off :
0 = see F0;
1 = always off with compressor off ;
2 = on for anti-stratifi cation;
3 = on for humidity control.
10 3 -SNO
F3 Evaporator fans during defrost: 0 = on; 1 = off .101-SNO
F4 Condenser fan deactivation temperature 40/ 104 -50/ -58 200/ 392 °C/°F S NO
F4r Humidifi cation output during defrosts:
0 = active based on humidity control;
1 = deactivated during defrosts
10 1 -SNO
F5 Evaporator fan cut-off temperature (hysteresis 1 °C) 5/41 F1 200/392 °C/°F S NO
F5d Condenser fan activation diff erential 5/ 9 0.1/ 0.2 60/ 108 Δ °C/ °F S NO
Fd Post-dripping time after defrost (fans off with control active) 2 0 15 min S NO
Fd0 Evaporator fan ON time for anti-stratifi cation during the day 5 1 100 min S NO
FdF Evaporator fan OFF time for anti-stratifi cation during the day (0 = always
ON during the day)
10 0 100 min S NO
Fn0 Evaporator fan ON time for anti-stratifi cation at night 5 1 100 min S NO
FnF Evaporator fan OFF time for anti-stratifi cation at night (0 = always ON
at night)
20 0 100 min S NO
Fpd Evaporator fans during post-dripping: 0 = on; 1 = off .101-SNO
Frd Evaporator fan activation diff erential (including variable speed) 2/ 3.6 0.1/ 0.2 20/ 36 Δ °C/°F S NO
GF Custom function associated with the specifi c button (Large models
only):
0 = Not confi gured; 1 = Light; 2 = Auxiliary output; 3 = Continuous cycle.
3 0 3 - S YES
GF1 Custom function associated with the UP arrow - see GF 2 0 3 - S YES
GF2 Custom function associated with the DOWN arrow - see GF 1 0 3 - S YES
GFA_1 Generic alarm function, control probe 1
0 = not confi gured;
1 = outlet temperature (Sm);
2 = defrost temperature (Sd);
3 = intake temperature (Sr);
4 = not used;
5 = not used;
6 = auxiliary evaporator defrost temperature (Sd2);
7 = auxiliary probe 1;
8 = auxiliary probe 2;
9 = ambient temperature;
10 = not used;
11 = glass temperature;
12 = not used;
13 = condensing temperature;
14 = humidity;
15 = frost protection temperature;
16 = product temperature.
0 0 16 - S NO
GFA_2 Generic alarm function, control probe 2 - see GFA_1 0 0 20 - S NO
GFA_D Generic alarm function, diff erential 0.1 0.1 99.9 - S NO
GFA_De Generic alarm function, delay 0 0 30000 S S NO
GFA_E Generic alarm function, enable
0 = always; 1 = unit ON; 2 = unit OFF;
3 = defrost; 4 = not used;
5 = continuous cycle; 6 = duty setting; 7 = standby;
8 = compressor or reverse output active;
9 = door open; 10 = active alarm.
8 0 10 - S NO
GFA_Hth Generic alarm function, high temperature threshold 0 GFA_Lth 999 - S NO
GFA_Lth Generic alarm function, low temperature threshold 0 -99 GFA_Hth - S NO
GFS_1 Generic On/Off function: control probe 1 - see GFA_1 0 0 16 - S NO
GFS_2 Generic On/Off function: control probe 2 - see GFA_1 0 0 16 - S NO
GFS_D Generic On/Off function, diff erential 0 0 99.9 - S NO
GFS_E Generic On/O function, enable - see GFA_E 8 0 10 - S NO
GFS_S Generic On/O function, set point 0 -99 999 - S NO
