Je bekijkt pagina 68 van 104
68
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Code Description Def. Min Max UOM User User term.
c11 Second compressor start delay 4 0 250 s S NO
c2 Min compressor OFF time 3 0 15 min S NO
c3 Min compressor ON time 0 0 15 min S NO
c4 ON time for duty setting operation (Toff = 15 minutes, fi xed value):
0 = compressor always OFF;
100 = compressor/valve always ON
0 0 100 min S NO
c7 Defrost priority over continuous cycle:
0 = continuous cycle has priority; 1 = defrost has priority.
00 1 -SNO
c8 Compressor start delay after opening the pump down valve 5 0 60 s S NO
c9 Restart during pump down: 0 = disabled; 1 = enabled 0 0 1 - S NO
cc Continuous cycle running time (0 = disabled) 0 0 72 hours S NO
ccE Set point delta to end continuous cycle 1.5/ 2.7 0.0/ 0.0 9.9/ 17.8 Δ °C/°F S NO
CnC Start continuous cycle 0 0 1 - S NO
cPt Maximum pump down time (0 = pump down disabled) 0 0 900 s S NO
d0 Type of defrost: 0 = heater by temperature;
1 = hot gas by temperature;
2 = heater by time;
3 = hot gas by time;
4 = heater by time with temperature control.
00 4 -SNO
d10 Compressor OFF time running time defrost - 0 = function disabled 0 0 240 min S NO
d11 Defrost temperature threshold in running time mode -50/ -58 -50/ -58 50/ 122 °C/°F S NO
d15 Start defrost threshold 0 0 240 min S NO
d16 Time with no temperature decrease before starting defrost 30 Add 240 min S NO
d20 Sampling time for alarm rSF 0 0 240 min S NO
d21 Number of defrosts allowed before signalling alarm rSF 2 1 5 - S NO
d22 Temperature diff erence to verify decrease 0.1/ 0.2 0.1/ 0.2 0.5/ 0.9 Δ °C/°F S NO
d4 Enable defrost at power on: 0 = disabled; 1 = enabled. 0 0 1 - S NO
d5 Defrost delay at start-up or after command from digital input 0 0 240 min S NO
d6 Display on terminals during defrost: 0 = temperature alternating with
‘dEF’; 1 = freeze display; 2 = ‘dEF’.
1 0 2 - S YES
d7 Skip defrost: 0 = disabled; 1 = enabled. 0 0 1 - S NO
d8 Bypass high temperature alarm time after defrost 1 1 240 hours S YES
d9 Defrost priority over compressor protection times:
0 = the compressor protection times are observed;
1 = the compressor protection times are ignored, therefore defrosting
starts without waiting for the compressor protection times to elapse
00 1 -SNO
dAS Activate ECO mode 0 0 1 - U NO
dC Time base for defrosts: 0 = dI in hours, dP1 and dP2 in minutes;
1 = dI in minutes, dP1 and dP2 in seconds.
00 1 -SNO
dC1 Time base for d8: 0 = d8 in hours; 1 = d8 in minutes 0 0 1 - S NO
dCH Defrost after opening the door: maximum number of openings 50 dcL 99 - S NO
dcL Defrost after opening the door: minimum number of openings 0 0 dCH - S NO
dd Dripping time after defrost (0 = no dripping) 2 0 15 min S NO
dfM Start defrost 0 0 1 - U NO
dHA Condensate drain heater activation time before defrosting 3 1 120 min S NO
dHE Condensate drain heater activation time after defrosting 3 1 120 min S NO
dHG Waiting time for compressor start to reverse cycle 0 0 300 s S NO
dI Maximum interval between consecutive defrosts 8 0 240 hours S YES
DIA Assign immediate external alarm digital input:
0 = Disabled; 1 = DI1; 2 = DI2; 3, 4 = Not available
(**) 0 4 - S NO
DIb Assign delayed external alarm digital input - see DIA (**) 0 4 - S NO
DIc Assign enable defrost digital input - see DIA (**) 0 4 - S NO
DId Assign start defrost digital input - see DIA (**) 0 4 - S NO
DIE Assign door switch with compressor OFF digital input - see DIA (**) 0 4 - S NO
DIF Assign remote ON/OFF digital input - see DIA (**) 0 4 - S NO
DIG Assign curtain switch digital input - see DIA (**) 0 4 - S NO
DIH Assign start/stop continuous cycle digital input - see DIA (**) 0 4 - S NO
DIP Assign door switch without compressor OFF digital input - see DIA (**) 0 4 - S NO
DIS Assign generic function alarm digital input logic - see DIA (**) 0 4 - S NO
DIt Assign low pressure switch digital input - see DIA (**) 0 4 - S NO
DIU Assign AUX output activation digital input - see DIA (**) 0 4 - S NO
dn Nominal defrost duration for skip defrost 75 0 100 % S NO
DOA Assign solenoid/compressor digital output
0 = not confi gured 4 = digital output 4 (NO4)
1 = digital output 1 (NO1) 5 = digital output 5 (NO5)
2 = digital output 2 (NO2) 6 = digital output 6 (NO6)
3 = digital output 3 (NO3)
(**) 0 6 - S NO
DOb Assign alarm digital output - see DOA (**) 0 6 - S NO
DOC Assign AUX auxiliary digital output - see DOA (**) 0 6 - S NO
DOE Assign light digital output - see DOA (**) 0 6 - S NO
DOG Assign defrost digital output - see DOA (**) 0 6 - S NO
DOH Assign auxiliary evaporator defrost digital output - see DOA (**) 0 6 - S NO
DOI Assign evaporator fan digital output - see DOA (**) 0 6 - S NO
DOj Assign dehumidifi cation heater digital output -
see DOA
(**) 0 6 - S NO
DOk Assign auxiliary compressor without rotation digital output - see DOA (**) 0 6 - S NO
DOn Assign pump down valve digital output - see DOA (**) 0 6 - S NO
DOP Assign condensate drain heater digital output -
see DOA
(**) 0 6 - S NO
DOQ Assign anti-sweat heater digital output - see DOA (**) 0 6 - S NO
DOS Assign generic On/Off function digital output - see DOA (**) 0 6 - S NO
DOt Assign condenser fan digital output - see DOA (**) 0 6 - S NO
DOu Assign humidifi cation digital output - see DOA (**) 0 6 - S NO
DOv Assign reverse digital output with dead band control -
see DOA
(**) 0 6 - S NO
DOw Assign auxiliary parallel compressor digital output -
see DOA
(**) 0 6 - S NO
DOx Assign gasket heater digital output -
see DOA
(**) 0 6 - S NO
DOy Assign auxiliary compressor with rotation digital output - see DOA (**) 0 6 - S NO
DOz Assign external dehumidifi er digital output - see DOA (**) 0 6 - S NO
