67
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Code Description Def. Min Max UOM User User term.
/cG Auxiliary temperature probe 1 calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cH Auxiliary temperature probe 2 calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cI Room temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cM Glass temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/co Condensing temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cp Humidity probe calibration 0 -20 20 Δ %rh S NO
/cq Frost protection temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cr Product temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/d1 Assign end defrost probe:
1 = outlet temperature (Sm);
2 = defrost temperature (Sd);
3 = intake temperature (Sr);
4 = not used;
5 = not used;
6 = auxiliary evaporator defrost temperature (Sd2);
7 = auxiliary probe 1;
8 = auxiliary probe 2;
9 = ambient temperature;
10 = not used;
11 = glass temperature;
12 = not used;
13 = condensing temperature;
14 = humidity;
15 = frost protection temperature;
16 = product temperature
2 1 16 - S NO
/d2 Assign auxiliary evaporator end defrost probe - see /d1 6 1 16 - S NO
/FA Assign outlet temperature probe (Sm)
0 = Function disabled 4 = Probe S4
1 = Probe S1 5 = Reserved
2 = Probe S2 6 = Not available
3 = Probe S3 7 = Not available
(**) 0 7 - S NO
/Fb Assign defrost temperature probe (Sd) - see /FA (**) 0 7 - S NO
/Fc Assign intake temperature probe (Sr) - see /FA (**) 0 7 - S NO
/FF Assign auxiliary evaporator defrost temperature probe
(Sd2) - see /FA
(**) 0 7 - S NO
/FG Assign auxiliary temperature probe 1 (Saux1) - see /FA (**) 0 7 - S NO
/FH Assign auxiliary temperature probe 2 (Saux1) - see /FA (**) 0 7 - S NO
/FI Assign ambient temperature probe (SA) - see /FA (**) 0 7 - S NO
/FM Assign glass temperature probe (Svt) - see /FA (**) 0 7 - S NO
/Fo Assign condensing temperature probe - see /FA (**) 0 7 - S NO
/FP Assign humidity probe (fi xed on S5) (**) 0 5 - S NO
/Fq Assign frost protection temperature probe - see /FA (**) 0 7 - S NO
/FR Assign product temperature probe - see /FA (**) 0 7 - S NO
/Lb Status LEDs on in standby (including ON/OFF):
0 = off ; 1 = on.
00 1 -SNO
/nE Enable user terminal navigation:
0 = enabled; 1 = disabled; 2 = On/Off disabled;
3 = On/Off and access to set point disabled.
00 3 -SNO
/P1 Confi guration of probes S1, S2, S3, S4, B5
0 = PT1000; 1 = PTC; 2 = NTC; 3 = NTC-LT; 4 = NTC-HT.
20 4 -SNO
/P2 Confi guration of multifunction input S3/ DI1:
0, 1, 2, 3, 4 = S3; 5 = DI1.
50 5 -SNO
/Sb PRG button always ON in standby: 0 = off ; 1 = on. 1 0 1 - S NO
/ta Alternating (temperature/humidity):
0 = disabled; 1 = enabled.
00 1 -SNO
/t1 Display on user terminal:
0 = Not confi gured 6 to 8 = not available
1 = value of S1 9 = control probe
2 = value of S2 10 = virtual probe
3 = value of S3 11 to 14 = not available
4 = value of S4 15 = actual control set point
5 = value of S5
9 0 15 - S YES
A0 High and low temperature alarm reset diff erential 2/ 3.6 0.1/0.2 20/ 36 Δ °C/°F S NO
A1 Alarm thresholds (AL, AH) relative to the set point St or absolute:
0 = relative; 1 = absolute.
00 1 -SNO
A3 Defrost terminated after maximum time signal:
0 = disabled; 1 = enabled.
00 1 -SNO
A5 (wizard only) Digital input (DI2) confi guration:
0 = Not confi gured 4 = NC door switch
1 = NO external alarm 5 = NO remote ON/OFF
2 = NC external alarm 6 = NC remote ON/OFF
3 = NO door switch
0 0 6 - U YES
A6 Stop compressor with external alarm (Toff = 15 minutes, fi xed):
0 = compressor always OFF; 100 = compressor always ON.
0 0 100 min S NO
A7 Delay time for delayed external alarm
(0 = signal-only alarm)
0 0 240 min S NO
Ac Dirty condenser alarm threshold 70/158 0/ 32 250/482 °C/°F S NO
Acd Dirty condenser alarm delay time 0 0 240 min S NO
Ad Delay time for high and low temperature alarms (AH, AL) 120 0 240 min U YES
Add High temperature alarm bypass time for door open 5 1 240 min U YES
AE Dirty condenser alarm reset diff erential 5 0.1/0.2 20/ 36 Δ °C/°F S NO
AF Frost protection alarm threshold -5/ -9 -50/ -58 200/392 °C/°F S NO
AFd Frost protection alarm delay time 1 0 15 min S NO
AH Relative high temperature alarm threshold 0 0 555/999 Δ °C/°F U YES
AHA Absolute high temperature alarm threshold 537/999 -100/ -148 537/999 °C/°F U YES
AL Relative low temperature alarm threshold 0 0 200/360 Δ °C/°F U YES
ALA Absolute low temperature alarm threshold -100/-148 -100/ -148 537/999 °C/°F U YES
AuC Activate auxiliary output 0 0 1 - S NO
BtE Enable Bluetooth™ connection: 0 = disabled; 1 = enabled. 1 0 1 - S NO
c0 Delay to enable compressor and evaporator fan at power on 0 0 15 min S NO
c1 Min time between consecutive compressor starts 0 0 15 min S NO
c10 End pump down: 0 = time; 1 = pressure. 0 0 1 - S NO
