Je bekijkt pagina 66 van 104
66
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
7.26 Zero crossing
The zero crossing feature is disabled by default. Carefully read the following instructions carefully for correct setup. The iJW con-
troller allows the relay to switch at the power supply voltage zero crossing. The feature can be activated on each relay.
Par. Description Def Min Max UOM User User terminal
DOT1 Enable zero crossing on digital output 1 (NO1)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
DOT2 Enable zero crossing on digital output 2 (NO2)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
DOT3 Enable zero crossing on digital output 3 (NO3)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
DOT4 Enable zero crossing on digital output 4 (NO4)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
DOT5 Enable zero crossing on digital output 5 (NO5)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
DOT6 Enable zero crossing on digital output 6 (NO6)
0 = Zero crossing not enabled;
1,2 = Reserved use;
3 = Zero crossing enabled.
003- SNO
Caution:
• the load must be directly connected to the relay: before enabling zero crossing, check that there is no external relay;
• The load must be powered by the same phase as the controller.
8. PARAMETER TABLE
Below is the table of the parameters that can be displayed on the terminal or can be modifi ed using the Applica Desktop con-
fi guration software or Applica app. In the Applica app and in the Applica Desktop confi guration software for iJW, the access level
to the Service (S) parameters is preconfi gured with default password 22.
Par. Description Def Min Max UOM User User terminal
PDS Service password 22 0 999 - S NO
PDU User password 0 0 999 - U NO
Notice:
• the read-only parameters are not visible from the Applica app using NFC, as NFC memory cannot be overwritten frequently;
• to avoid any fraudulent activities, the default password values should be changed at the end of the commissioning procedure.
For example, with the Applica app, parameters PDS and PDU can be used to set the new password, with a maximum length
of 3 numbers.
Caution: the operation to reset the default values is not reversible, unless a user recipe has been previously saved for load-
ing using the Applica Desktop confi guration software/Applica app, see the paragraph on the confi gurations.
8.1 Parameter table
Code Description Def. Min Max UOM User User term.
/2 Analogue probe measurement stability:
0 = probe reading not delayed;
…
9 = maximum probe reading delay.
50 9 -SNO
/3 Display probe value:
0 = disabled;
1 = fast update;
...
15 = slow update.
0 0 15 - S NO
/4 Virtual probe composition:
0 = Air off probe Sm; 100 = Air on probe Sr
0 0 100 % S NO
/5 Unit of measure: 0 = °C; 1 = °F. 0 0 1 - U YES
/6 Display decimal point: 0 = Yes; 1 = No. 0 0 1 - S YES
/cA Outlet temperature probe (Sm) calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cb Defrost temperature probe (Sd) calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cc Intake temperature probe (Sr) calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
/cF Auxiliary evaporator defrost temperature probe (Sd2) calibration 0 -20/ -36 20/ 36 Δ °C/°F S NO
