52
Hecu +0300023EN rel. 1.2 - 14.12.2021
Screen
index
Enable screen Description Serious
alarm
Normal
alarm
Action Description
ALW41 MPX_1_Alm_LTD Store 1: Low temperature alarm x / Low temperature alarm of the probe set in
the MPXPRO / UC
ALW42 MPX_1_Alm_HTD Store 1: High temperature alarm x / High temperature alarm of the probe set in
the MPXPRO / UC
ALW43 MPX_1_Alm_LTS Store 1: Low temperature alarm 2 x / Low probe temperature alarm set only for
MPXPRO
ALW44 MPX_1_Alm_HTS Store 1: High temperature
alarm 2
x / High temperature alarm of the probe set
only for MPXPRO
ALW45 MPX_1_Alm_Defrost_Timeout Store 1: Defrost timeout x / Signalling of end of defrost procedure due
to timeout
ALW46 MPX_1_Alm_LSH Store 1: Low superheat alarm x / SH falls below a certain threshold and only
integral adjustment of the valve is activated
to close it faster and avoid liquid backfl ow
to the compressor.
ALW47 MPX_1_Alm_LSA Store 1: Low suction temperature
alarm
x / Suction temperature (t_gs) falls below a
certain threshold with risk of liquid return
to the compressor
ALW48 MPX_1_Alm_MOP Store 1: MOP alarm x / Evaporation pressure in the cabinet,
expressed in saturated degrees, exceeds a
certain threshold settable by MPXPRO (pa-
rameter PM1) the normal setting is replaced
by an integral only setting (parameter PM2)
to quickly close the Carel E2V electronic
valve
ALW49 MPX_1_Alm_LOP Store 1: LOP alarm x / Evaporation pressure in the cabinet,
expressed in saturated degrees, falls below
a certain threshold settable by MPXPRO
(parameter PL1) an integral adjustment
(parameter pL2) is added to the normal ad-
justment to open the Carel E2V electronic
valve faster
ALW50 MPX_1_Alm_Edc Store 1: stepper driver communi-
cation error
x / Incorrect setting of parameter P1 in MPX-
PRO, which must be set to 2 (mandatory
management of Carel E2V electronic valve).
ALW51 MPX_1_Alm_EFS Store 1: Stepper motor error x
ALW52 MPX_1_Alm_bLO Store 1: Installation or confi g
problems on EEV driver
x / Valve alarm at end of stroke.
Valve block alarm signalling (“Blo”) in
MPXPRO
ALW53 al_Mpx2_Offl ine Store 2 offl ine x / Evaporator 2 confi gured by Hecu but
MPXPRO / UC device not connected via
Fieldbus or offl ine
ALW54 MPX_2_Alm_LTD Store 2: Low temperature alarm
[air off ]
x
ALW55 MPX_2_Alm_HTD Store 2: High temperature alarm
[air off ]
x
ALW56 MPX_2_Alm_LTS Store 2: Low temperature alarm
[air on]
x
ALW57 MPX_2_Alm_HTS Store 2: High temperature alarm
[air on]
x
ALW58 MPX_2_Alm_Defrost_Timeout Store 2: Defrost timeout x
ALW59 MPX_2_Alm_LSH Store 2: Low superheat alarm x
ALW60 MPX_2_Alm_LSA Store 2: Low suction temperature
alarm
x
ALW61 MPX_2_Alm_MOP Store 2: MOP alarm x
ALW62 MPX_2_Alm_LOP Store 2: LOP alarm x
ALW63 MPX_2_Alm_Edc Store 2: stepper driver communi-
cation error
x
ALW64 MPX_2_Alm_EFS Store 2: Stepper motor error x
ALW65 MPX_2_Alm_bLO Store 2: Installation or confi g
problems on EEV driver
x
ALW66 al_Mpx3_Offl ine Store 3 offl ine x / Evaporator 3 confi gured by Hecu but
MPXPRO / UC device not connected via
Fieldbus or offl ine
ALW67 MPX_3_Alm_LTD Store 3: Low temperature alarm
[air off ]
x
ALW68 MPX_3_Alm_HTD Store 3: High temperature alarm
[air off ]
x
ALW69 MPX_3_Alm_LTS Store 3: Low temperature alarm
[air on]
x
ALW70 MPX_3_Alm_HTS Store 3: High temperature alarm
[air on]
x
ALW71 MPX_3_Alm_Defrost_Timeout Store 3: Defrost timeout x
ALW72 MPX_3_Alm_LSH Store 3: Low superheat alarm x
ALW73 MPX_3_Alm_LSA Store 3: Low suction temperature
alarm
x
