20 Instruction manual RBL7 Please keep this instruction manual for future reference
REPLACING THE LED LIGHT
LIGHT SOURCE ENERGY CLASS
ThisproductcontainsalightsourceofenergyefciencyclassE.
1
2
3
4
5
1. Remove the screw on the light cover by screw driver. (Fig.1)
2. Press the hooks on light cover. (Fig.2)
3. Open the light cover towards arrow when top hooks pull out from housing. (Fig.3)
4. Pull out the cover towards arrow remove it. (Fig.4)
5. Turn the light bulb counter clockwise and remove it. (Fig.5)
6. Change the present light bulb with a new one of not more than 15W. (Fig.5)
7.Implement the steps in reverse order.
8.After waiting 5 minutes, plug the unit.
Unplug the unit from the power supply before starting the process.
LIGHT SOURCE ENERGY CLASS
This product contains a light source of energy efficiency class F.
The LED light must be replaced by an authorised engineer or similar only. For more
information, please contact Caple service - 0117 938 7420 or service@caple.co.uk
Unplug the unit from the power supply before starting the process.
1
2
3
4
5
1. Remove the screw on the light cover by screw driver. (Fig.1)
2. Press the hooks on light cover. (Fig.2)
3. Open the light cover towards arrow when top hooks pull out from housing. (Fig.3)
4. Pull out the cover towards arrow remove it. (Fig.4)
5. Turn the light bulb counter clockwise and remove it. (Fig.5)
6. Change the present light bulb with a new one of not more than 15W. (Fig.5)
7.Implement the steps in reverse order.
8.After waiting 5 minutes, plug the unit.
Unplug the unit from the power supply before starting the process.
LIGHT SOURCE ENERGY CLASS
This product contains a light source of energy efficiency class F.
1
2
3
4
5
1. Remove the screw on the light cover by screw driver. (Fig.1)
2. Press the hooks on light cover. (Fig.2)
3. Open the light cover towards arrow when top hooks pull out from housing. (Fig.3)
4. Pull out the cover towards arrow remove it. (Fig.4)
5. Turn the light bulb counter clockwise and remove it. (Fig.5)
6. Change the present light bulb with a new one of not more than 15W. (Fig.5)
7.Implement the steps in reverse order.
8.After waiting 5 minutes, plug the unit.
Unplug the unit from the power supply before starting the process.
LIGHT SOURCE ENERGY CLASS
This product contains a light source of energy efficiency class F.
