Instruction manual C895C 27
Please keep this instruction manual for future reference
the
lace
℃
NOTE:
For safety the distance between the hob and the cupboard above should be at least 760mm.
WARNING:
Ensuring adequate ventilation
Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In
order to avoid accidental touch with the overheating bottom of the hob, or getting an unexpected
electric shock during working, it is necessary to put a wooden insert, xed by screws, at a
minimum distance of 50mm from the bottom of the hob.
Follow the requirements below:
There are ventilation holes around the outside of the hob. YOU MUST ensure these holes are not
blocked by the worktop when you place the hob in position.
The rear wall, adjacent and surrounding surfaces must be able to withstand an temperature
of 90°C.
WARNING: Ensuring adequate ventilation
Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In
order to avoid accidental touch with the overheating bottom of the hob, or getting an
unexpected electric shock during working, it is necessary to put a wooden insert, fixed by
screws, at a minimum distance of 50mm from the bottom of the hob.
Follow the requirements below:
Min. 50mm
Max. 5mm Max. 5mm
