ORIFICE CHANGE - RANGETOP SECTIONS
(CONTINUED)
BURNER CAP
ALIGNMENT PIN
BURNER BASE
AIR SHUTTER
IGNITER
6. With the burner removed, you can now replace the orice. Make a note of how many threads you
can see at the base of the orice. Install the new orice to roughly this same distance. (Fig. 4)
7. Use a 1/2” wrench or locking pliers to prevent the brass elbow from rotating and a 1/2” socket
wrench to remove the orice. Try not to disturb the gas ex hose. There is a large locknut just
below the orice which must remain tight against the bracket. (Fig. 5)
8. Installation is the reverse of this procedure. Do not use any pipe dope or sealant on the threads.
Install the new orice slowly to avoid cross-threading and damaging the threads. Consult the
table below for identication of orice sizes. The orice will become noticeably harder to turn
as you proceed. Use the same technique as shown in step 7 to prevent the elbow from rotating.
Check to make sure the locknut is tight against the bracket, and the orice must be roughly in the
same position as mentioned in step 6. Reattach the ex hose (if removed).
9. Reconnect the igniter wire and reinstall the burner base and cap. Use the alignment notches
and/or pins on the burner base to help with proper alignment. Incorrect alignment will produce
a potentially dangerous ame and poor burner performance.
10. The air shutter will require adjustment. This will be explained in the AIR SHUTTER ADJUSTMENT
section. Do not reinstall any other components until the shutter adjustment and leak tests are
completed.
11. Repeat this procedure for the remaining Open Burner orices.
Fig. 5
Fig. 4
RANGETOP ORIFICES
ALTITUDE
RANGE/RANGETOP
MODEL FAMILY
BURNER LOCATION BURNER TYPE NG LP
NG
ORIFICE
SIZE
LP
ORIFICE
SIZE
FRONT OPEN 25000 25000 43 1.45mm
REAR OPEN 25000 25000 43 1.45mm
REAR LEFT OPEN - SMALL PAN 8000 8000 56 70
FRONT OPEN 25000 25000 45 54
REAR OPEN 25000 25000 45 54
REAR LEFT OPEN - SMALL PAN 8000 8000 57 71
BURNER OUTPUT
(BTU/hr.)
ORIFICE INFO
Sea Level - 1999 . [600 m]
2000 - 6000 . [600 - 1800 m]
MCOR, CGSR, CGRT
© 2025 Capital Cooking
4
EN
