Adjusting Print Head Position Manually
Any error in the print head installation position can cause color and line shifts. Adjusting the print head
position improves print results.
Print head position can be adjusted either automatically or manually.
These instructions are for performing Print Head Alignment manually.
Important
• A pattern will be printed for head alignment. Do not open the scanning unit / cover while printing is in
progress.
Print Head Alignment
1.
Open Canon IJ Printer Assistant Tool
1.
2. Check that the printer power is on, and then click Other Settings2.
The Other Settings dialog box appears.
3.
Set to manual adjustment
3.
Select Align heads manually.
4. Apply settings4.
Click OK. When the confirmation message appears, click OK.
5. Click Print Head Alignment5.
The Print Head Alignment dialog box appears.
6.
Load paper in printer
6.
Load three sheets of A4 size or Letter size plain paper into the rear tray.
7.
Run head position adjustment
7.
Click Start.
Perform the necessary operations by following the message instructions.
8.
Check printed patterns
8.
In each entry field, enter the number of the pattern with the least prominent streaks from among the
printed patterns.
You can also enter numbers into the entry fields automatically by clicking relevant pattern in the
preview.
129
