87
Chapter 6: Appendixes
...
2. Installing Software
Printing method
Print color
Resolution
Print speed
Maximum effective print area (W x L)
Print margins
Printhead
Paper Type
Size
Thickness
Paper stack capacity
Ink Type
Storage life and temperature
Interface
Interface connector
Recommended printer cables
Material
Type
Length
Connector
Dimensions (W x D x H)
Weight
Storage environment
Operating environment
Power consumption
Normal mode
Power saving
mode
Bubble Jet printing
Full color
600 dpi x 600 dpi
80 name cards/min
35 postcards/min
102 mm x 297 mm
Leading edge 1.5 mm (0.06 in.), Trailing edge 1.5 mm (0.06 in.)
Left/right 2.0 mm (0.08 in.) (width: 106mm or less)
2,432 x 6 nozzles (effective printing nozzles = 2,400)
Specialty paper (Matte coated, Glossy)
Width: from 80 to 120 mm
Length: from 49 to 300 mm
Name card/postcard: from 0.23 mm to 0.30 mm
Envelope: from 0.28 mm to 0.32 mm
250 name cards, 500 postcards (paper thickness: 0.24mm or less)
Envelope: 100 to 200 envelopes (depends on size)
Supplied ink cartridge for P-660C:
Yellow (Y), Light Magenta (LM), Magenta (M), Light Cyan (LC)
Cyan (C), Black (Bk)
1 year: 0 ˚C • 5 % to 35 ˚C • 90 % (humidity, non-condensing)
IEEE 1284 compliant Parallel Universal Serial Bus (USB)
IEEE 802.3 10BASE-T (TCP/IP, IPX/SPX)
Amphenol 57-40360 or equivalent
USB (Series B) receptacle RJ45-8 pin modular connector
AWG28 or larger AWG28 or larger AWG22 - AWG26
Shielded twisted pair cable Shielded twisted pair cable Unshielded twisted pair cable
(supporting full-speed mode )
maximum 2.0 m maximum 2.0 m less than 100 m *
1
Amphenol 30360 or equivalent USB (Series B) plug RJ45-8 pin modular connector1
650 mm (W) x 440 mm (D) x 470 mm (H)
approx. 36 kg (Main unit only)
5 ˚C • 10 % to 35˚C • 90% (humidity, non-condensing)
15 ˚C • 10 % to 30˚C • 80% (humidity, non-condensing)
330W (Max.)
35W (Max.)
*1 Note, when using the 10BASE-T cable connection, that the number of connectable repeater HUB is re-
stricted to four at most, according to the Ethernet standards.
It is also recommended not to use unnecessarily long cables.
3. Specifications
