32
11-Technical data
EN
11-Technical data
11.1 Additional technical data
Voltage in V 220-240 V~/50Hz
Current in A 10
Max power in W 1950
Water pressure in MPa 0.03≤P <1
Net weight in kg
11.2 Product dimensions
PRODUCT DIMENSIONS
H Overall height of product mm
W Overall width of product mm
D5 overall depth of product
(To main control board size)
mm
D1 Overall depth of product mm
D2 Depth of door open mm
D4 Minimum door clearance to
adjacent wall mm
11.3
Standards and Directives
This product meets the requirements of applicable EC directives with the corresponding
harmonised standards, which provide for CE marking.
WALL
TOP VIEW
FRONT VIEW
62
Note:
The exact height of your washer is dependent on how far the feet are extended from
the base of the machine. The space where you install your washer needs to be at least
40mm wider and 20mm deeper than its dimensions.
58
850
595
491
533
1015
300
GD 48SB6-S
GD 410B8-S
850
595
559
601
1084
300
GD 410B8-S GD 48SB6-S
62
GD 49B8-S
850
595
559
601
1084
300
GD 49B8-S
H
W
D2
D4
D5
D1
