CBFI SERIES
INLINE EXHAUSTER
M-CBFI-L 08/24 Page 4 of 5
#
.
,
1'&'"!;%"&%9;?!%9/7!9-;-.%;%9,-%,;?
.';2%9#B3
"9!;&A
;'$7'!<6) 66"?
;
#
E
C6D"
216
!
;?
606:*
#
.
,
.';2%9#B3 "9!;&A
;'$7'!166"?
;
E
!
C6D"
6C6D-"F
#
&
6C6D-"$
216
"#
$
21)66
"
%"
"
21)66
$
21)66
"$
%
21766
$
$
STANDARD WIRING INSTRUCTIONS
VARIABLE SPEED CONTROL
AC SUPPLY – 120VAC
1. All wiring should be completed by a qualified electrician in accordance with National Electrical Codes and all local ordinances.
2. Ensure power supply is disconnected and locked out prior to making electrical connections.
3. Complete all connections as required for your layout.
4. Excess wire coming into the unit must be restrained cleanly and safely within the ceiling.
5. Switches are recommended and should be located near the fan in order to swiftly cut off power in case of an emergency and to
maintain complete control of the power source.
PRE-START INSPECTION
1. Lock out all power sources. Shut off circuit at the breaker panel.
2. Inspect all fasteners and make sure that all are tight (some may have loosened during shipping).
3. Confirm power source voltage and motor voltage are the same and that the motor is wired correctly.
4. Rotate the wheel to ensure that it rotates freely and that nothing comes in contact with the housing.
5. Inspect the fan and ductwork to ensure they are free of debris.
6. Check to ensure that all guards and accessories are securely installed.
7. Ensure all insulation is fastened and tight.
A 0v to 10v potentiometer comes standard and is pre-wired into your CBFI unit to control the speed and performance of the fan.
WARNING: NOT SUITABLE FOR USE WITH SOLID STATE SPEED CONTROLS
Power is connected to the motor through the wiring cover. Power leads run direct from the motor and are restrained in the units’ housing.
Be sure to use a strain relief on the wiring, where the power supply passes through into the unit.
0.17A
9.9W
0.24A
10.4W
100CFM @ 0.125” SP 128CFM @ 0.125” SP
0.59A
39.9W
225CFM @ 0.125” SP
2.0A
152W
592CFM @ 0.125” SP
208CFM @ 0.125” SP
253CFM @ 0.125” SP
0.38A
24.4W
0.78A
53W
