28
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
MINIMUM DISTANCE TO ILLUMINATED SURFACE
0.5m
This symbol with distance specification in metres (m) indicates the minimum
distance between the light head and the illuminated surface. In this example, the
distance is 0.5m. The value applicable for this unit can be found in the technical
data in this manual and the imprint on the unit housing!
MINIMUM DISTANCE TO NORMALLY FLAMMABLE MATERIALS
0.5m
This symbol with distance specification in metres (m) indicates the minimum
distance between the light head and normally flammable materials. In this example,
the distance is 0.5m. The value applicable for this unit can be found in the
technical data in this manual!
Operation
voltage
100V AC – 240V AC; 50Hz-60Hz 100V AC – 240V AC; 50Hz-60Hz
Max. current 0.38A @230V; 0.67A @110V 0.54A @230V; 1.09A @110V
Inrush current 13.3A 13.3A
Max. power
consumption
87W @230V; W 74@110V 124W @230V; W 120@110V
Fuse T2A T2A
Cos Phi 0.990 0.998
Minimum
distance to the
illuminated
surface
0,5 m 0,5 m
Minimum dis-
tance to normal
flammable
materials
0,5 m 0,5 m
Power
connectors
IN: Power Twist Blue; OUT: Power
Twist White
IN: Power Twist Blue; OUT: Power
Twist White
Power link 27 Units @230V / 15 Units @ 110V 20 Units @230V / 9 Units @ 110V
Housing Aluminium die cast, black powder
coated
Aluminium die cast, black powder
coated
Dimensions
h/w/d
Over All: 360 x 245 x 314 / Floor-
mount: 328 x 267 x 314
Over All: 360 x 245 x 314 / Floor-
mount: 328 x 267 x 314
Weight 4.9 kg 4.9 kg
