21
DMX
DEUTSCHFRANCAIS
ESPAÑOL
ENGLISH
ITALIANO POLSKI
Assign the spotlights to one of up to 24 groups (plus Group 0) according to preference, whereby
several spotlights can be assigned to one group. The group number is also the factor by which the
delay time set in the master unit is multiplied.
Setup example:
Mode
Slave
Mode
Slave
Delay Group 0
no Delay
Master Unit
Loop Delay 0.5s
Delay Group 1
0,5s Delay
Mode
Slave
Delay Group 2
1s Delay
Mode
Slave
Mode
Slave
Mode
Slave
Delay Group 3
1,5s Delay
Mode
Slave
Delay Group 4
2s Delay
Mode
Slave
Delay Group 5
2,5s Delay
Group 1 Group 2
Group 3
Group 3
Group 3
Group 4 Group 5
Group 0
SYSTEM SETTINGS (Settings)
Starting from the main display, press MENU to enter the main menu. Using
and , select the
menu item Settings and confirm with ENTER.
Menu
DMX Address
DMX Mode
DMX Delay
Stand Alone
Slave
Settings
System Info
This will take you to the submenu for setting the submenu items (see table, select with and ,
confirm with ENTER, change value or status with and , confirm with ENTER).
Settings
Disp Rev = Rotate display Off No display rotation
On Display is rotated by 180° (e.g. for over-
head installation)
Display
Off Timer
= Display lighting Off after
20s
Deactivates after approximately 20 sec-
onds of inactivity
Always On On permanently
Signal
Fail
= Operational status with
DMX signal fault
Hold Last command is retained
Blackout Activates blackout
Fade 10s fade to blackout
User Colour
1
User Colour 1 is activated
PWM = LED PWM frequency 650Hz,
1530Hz,
3600Hz,
12000Hz,
18900Hz,
25000Hz
Select LED PWM frequency
