INTRODUCTION
OUTDOOR UPLIGHT SPOTLIGHT WITH 4 X 15 W RGBWA+UV LEDS AND W-DMX™
CLDROPP4
CONTROL FUNCTIONS
• 3-channel, 4-channel, 6-channel 7-channel, 13-channel 1, 13-channel 2 and 20-channel DMX functions
• W-DMX™
• Standalone functions
• Control via IR remote control (remote control optionally available)
FEATURES
• 4 x 15 W RGBWA+UV LEDs
• Outdoor housing with IP65 protection class.
• 3-pin XLR connections. W-DMX receiver integrated
• OLED display
• Convection cooling
• Removable stand and mounting bracket for discreet uplight function
• Tilt adjustment screw
• 2 diffusers included.
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
1
POWER IN
TRUE 1 compatible power input socket. Operating voltage 100–240 V AC/50–60 Hz. A suitable mains cable with IP65 plug is included. When
not in use, always close with the appropriate rubber sealing cap.
2
POWER OUT
TRUE 1 compatible mains output socket for supplying power to additional Cameo headlights (for maximum output current, see label on back
of housing). When not in use, always close with the appropriate rubber sealing cap.
3
DMX IN
Male IP65 3-pin XLR socket for connection to a DMX control device (e.g. DMX console) When not in use, always close with the appropriate
rubber sealing cap.
4
DMX OUT
Female IP65 3-pin XLR socket for sending the DMX control signal. When not in use, always close with the appropriate rubber sealing cap.
PLEASE NOTE: To protect the input and output sockets from splash water in accordance with IP65 protection class, they
must be correctly closed using the appropriate IP65 plugs or the rubber sealing caps must be used to close them.
1 2 4 3
