TECHNICAL DATA
Product number: CLDROPP4
Product type: LED wash light
Type: Outdoor spotlight
Color spectrum LED: RGBWA+UV
Number of LEDs: 4
LED type: 15 W
PWM frequency: 800 Hz
Beam angle: Beam Angle 22° / Field Angle 38°
1. Filter Medium BA 32°
2. Filter Wide BA 45°
DMX input: 3-pin
DMX output: 3-pin
DMX mode: 20-channel / 13-channel 2/ 13-channel 1 / 7-channel / 6-channel / 4-channel / 3-channel
DMX functions: Dimmer, Dimmer Fine, RGBWA+UV, RGBWA+UV Fine, Stroboscope, Color Macros, Color Change, Color
Blending, System Settings
Standalone functions: Color Mixing, Color Macros, Auto Programmes, Loop Function, User Color, Master/Slave Mode
Control: DMX, W-DMX, RDM
Operating controls: Menu, Enter, Up, Down
Display elements: OLED display
Operating voltage: 100–240 V AC / 50–60 Hz
Power consumption: 45 W
Light intensity
(@ 1 m/3 m):
6750 lx / 755 lx
Luminous flux: 1100 lm
CRI: White LED > 79
Power supply connection: TRUE1 compatible input (output max 11 A)
Ambient temperature
(in operation):
0 – 40 °C
Protection class: IP65
Power supply certificate: CE, RoHS, ETL, FCC
Housing material: Metal
Housing color: Black
Housing cooling: Convection cooling
Dimensions (W x H x D,
without bracket):
186 mm x 170 mm x 170 mm
Weight: 2.8 kg
Additional features: 1x True1 compatible power cable, 2x filters and 1x mounting bracket included
