4
TIP: It is easier to start rail installation from the bottom and move up.
1. Follow the number guides etched into the columns of the cart to place your sheet pan, food pan,
tray or pizza box in the correct position. For example, to achieve standard capacity for full-sized
sheet pans, place the rails at positions 1, 3, 5, 7, 9, 11, 13 and 15.
2. Insert the top tabs into the front and corresponding middle and rear slots of the column.
3. Slide the rails towards the back of the cart then rotate it down into a nested position.
4. Install the subsequent rails into position following the appropriate numbering guide. Once the
rails have been installed on one side of the cart, repeat instructions to congure the other side.
5. To install position 16, remove screw and bumper, remove side column, insert rail, slide column
back in, replace screw and bumper. Repeat on other column.
Before operating the cart, install rails based upon your facility’s needs.
Each cart ships standard with 8 pairs of rails per compartment. Save extra rails for future use.
III. Rail Installation and Capacity Guide
TYPE OF CONTAINER
TALL CART
STANDARD
CAPACITY
LOW CART
STANDARD
CAPACITY
SET-UP AT NUMBERS ON
COLUMN
TALL CART
MAXIMUM
CAPACITY
LOW CART
MAXIMUM
CAPACITY
18" x 26" (45,7 x 66 cm) Full Size Sheet Pans 16 8
1, 3, 5, 7, 9, 11, 13,15
32* 16*
13" x 18" (33 x 45,7 cm) Half Size Sheet Pans 32 16 64* 32*
20
11
/16" x 13
1
/4" x 2
5
/16" Wire Basket 32 16 1, 3, 5, 7, 9, 11, 13,15 32 16
GN 1/1 Hotel Pans 2
1
/2" (6,5 cm) Deep 32 16 1, 3, 5, 7, 9, 11, 13,15 32 16
GN 1/1 Hotel Pans 4" (10 cm) Deep 20 10 1, 4, 7, 10, 13 20 10
40 x 60 cm (20
1
/2" x 23
1
/2") Trays 16 8 1, 3, 5, 7, 9, 11, 13,15 30* 16*
32 x 53 cm (12" x 20") Trays 32 16
1, 3, 5, 7, 9, 11, 13,15
64* 32*
Pizza Boxes 16" x 16" x 2" (40,6 x 40,6 x 5,1 cm) 16 8 16 8
*Additional rails required. Contact your local Cambro rep or dealer to purchase additional rails.
