Product Description 18
Rain Attenuation
Heavy Rain (25 mm/hr) 9.5 dB/km
Downpour (50 mm/hr) 17 dB/km
Tropical (100 mm/hr) 28 dB/km
Monsoon (200 mm/hr) 38 dB/km
The following figure shows the absorption loss due to the rain level (seasons):
Figure 3:
Variation in Loss/km with frequency and rain rate
Drizzle - 0.25 mm/hr; Light rain - 2.5 mm/hr; Medium rain - 12.5 mm/hr; Heavy rain - 25 mm/hr.
l
Short range
The range of a 60 GHz cnWave link can be limited due to oxygen absorption and rain fade which needs to be
factored in for link planning. One advantage of a shorter range is the frequent reusability and security (as the
signal does not travel long distances).
802.11ay Standards and advantages
IEEE 802.11ay is an IEEE standard that covers 60 GHz cnWave, this standard is an amendment of the IEEE 802.11ad
standard. There are IEEE 802.11ay is designed with a higher throughput capacity of over 10 Gbps data rate over
distances of 200 to 500 meters. 802.11ay includes features such as Channel Bonding and Synchronization. 802.11ay
based 60 GHz solution transforms fixed wireless access from a broadband option of last resort into a competitive
alternative to fiber and cable-based solution.
This standard is designed with a throughput capacity of over 10 Gbps data rate over distances of 200 to 500 meters.
802.11ay includes features such as Channel Bonding and Synchronization. 802.11ay is WLAN type in the IEEE
802.11. It has a frequency of 60 GHz. It has also been noted that it is likely to have mechanisms for channel bonding
and MU-MIMO technologies. 802.11ad uses a maximum of 2.16 GHz bandwidth, whereas 802.11ay bonds four of
those channels together for a maximum bandwidth of 8.64 GHz.
