cnReach N500 User Guide System Configuration

phn-4980_001v004 August 2019)

2-59

PLC Menu

The PLC feature enables the operator to configure cnReach to “act” on a local I/O input event to trigger

local I/O output. The input event handler is programmable using a BASIC-like language, strictly

following BASIC syntax.

Any cnReach with IO capability can host a Local PLC module . The PLC module is a separate software

module that must be downloaded from the support website and installed separately.

PLC is only supported on OS version 5.2.17 and above. A PLC software module needs to be uploaded

and applied to the OS. This separate PLC software module should be downloaded from the

support website and installed on the management/files pages just as an OS upgrade would be

installed. After installation, the PLC menu and options will be visible in the GUI.

This PLC module executes the supplied BASIC language code approximately once every 100ms.

LOCAL PLC Supported Functions

int = fnCRGet(Reg) - Get coil register from Modbus registers.

int = fnDRGet(Reg) - Get discrete register from Modbus registers.

int = fnHRGet(Reg) - Get holding register from Modbus registers.

int = fnIRGet(Reg) - Get input register from Modbus registers.

int = fnHRGetFloat(Reg) - Get float from holding register and register+1, from Modbus registers.

fnCRSet(Reg,Val) - Set coil register in Modbus registers. Val is 0 or non-zero.

fnHRSet(Reg,Val) - Set holding register in Modbus registers. Val is 16 bits, unsigned.

fnHRSetFloat(Reg,Val) - Set float in holding register and register+1, in Modbus registers. Val is float/real.

fnGetSeconds() - Get float/real of uptime seconds.

LOCAL PLC Supported BASIC Language Key Words

Reserved Keywords:

REM, TRUE, FALSE, NIL, MOD, AND, OR, NOT, IS, LET, DIM, IF, THEN, ELSEIF, ELSE, ENDIF, FOR, IN, TO,

STEP, NEXT, WHILE, WEND, DO, UNTIL, GOTO, GOSUB, RETURN, CALL, DEF, ENDDEF, ME, NEW, VAR,

REFLECT, MEM, TYPE, END.

Standard Library:

ABS, SGN, SQR, FLOOR, CEIL, FIX, ROUND, SRND, RND, SIN, COS, TAN, ASIN, ACOS, ATAN, EXP, LOG,

ASC, CHR, LEFT, LEN, MID, RIGHT, STR, VAL, PRINT.

PRINT:

PRINT "string" - print string without trailing carriage return/line feed.

PRINT "string"; - print string with trailing carriage return/line feed.
