cnReach N500 User Guide

Tasks and Best Practices

phn-4673_002v000 (March 2018)

4-14

Using the Status LEDs for Diagnostics

LINK/PWR - Access Point: green at all times. End Point: green indicates the link is up, red indicates the

link is down. Intermittent flickering red indicates a mismatch in RF Transmission Settings between

Access Point and End Point and the likelihood that traffic is not moving. Verify Access Point and End

Point RF Transmission settings to ensure Frequency and MMS parameters match.

XMIT/TX - Lights up red when transmitting data; bright for large packets with almost continuous

transmission; dim for small packets in quick succession; off for not transmitting at all.

RCV/RX - Lights up green when receiving data; bright for large packets with almost continuous

reception; dim for small packets in quick succession; off for not receiving at all.

If the RCV/RX LED is excessively flickering on a live network that’s passing data, the link may be

marginal; Check the Radio Diagnostics page for signal and noise levels.

Note

Increasing the Beacon Period on the Access Point slows down the RCV/RX LED blinking

rate on the End Point when the link is idle; i.e. not passing traffic.
