cnReach N500 User Guide
Technical Reference
phn-4673_002v000 (March 2018)
3-50
Channel and Hop Tables (900 MHz ISM Band Only)
The number of ISM channels varies with modulation
1
. The following sections provide channel
frequencies, spacing, bandwidth and minimum channel requirements for the available FHSS and DTS
ISM modulations.
The radio generates hop tables automatically based upon the modulation and frequency range in use.
The following is true for the complete 902-928 MHz ISM Band;
– 57 MSK 171 channels with 76.45 kHz bandwidth 1.
– 114 MSK 165 channels with 154.29 kHz bandwidth.
– 153 MSK 123 channels with 207.11 kHz bandwidth.
– 229 MSK 82 channels with 309.97 kHz bandwidth.
– 663 2FSK 26 channels with 900 kHz bandwidth.
– 884 BPSK 20 channels with 1.2 MHz bandwidth.
– 1768 QPSK 20 channels with 1.2 MHz bandwidth.
– 2651 8PSK 20 channels with 1.2 MHz bandwidth.
– 3535 16QAM 1 20 channels with 1.2 MHz bandwidth.
– 3535 16PSK 1 20 channels with 1.2 MHz bandwidth.
– 4419 32QAM 1 20 channels with 1.2 MHz bandwidth. provides
1
57 MSK uses the lower ISM band (902–915 MHz) even when Band Stop is set to 928 MHz.
Additionally, using the Exclude MHz settings to exclude 902 – 915 MHz has no effect and the Radio will
continue to use the lower half of the ISM band.
To force the radio to use the upper ISM Band (915 – 928 MHz), set Band Start to 915 MHz and Band Stop
to 928 MHz.
The radio will then use the upper half of the ISM Band maintaining 166 channels with 76.45 kHz channel
bandwidth.
57 MSK (FHSS)
171 channels with 76.45 kHz channel spacing / bandwidth
1
.
Ch
Freq (MHz)
Ch
Freq (MHz)
Ch
Freq (MHz)
Ch
Freq (MHz)
1
902.288225
44
905.575575
87
908.862925
130
912.150275
2
902.364675
45
905.652025
88
908.939375
131
912.226725
3
902.441125
46
905.728475
89
909.015825
132
912.303175
4
902.517575
47
905.804925
90
909.092275
133
912.379625
5
902.594025
48
905.881375
91
909.168725
134
912.456075
6
902.670475
49
905.957825
92
909.245175
135
912.532525
7
902.746925
50
906.034275
93
909.321625
136
912.608975
8
902.823375
51
906.110725
94
909.398075
137
912.685425
9
902.899825
52
906.187175
95
909.474525
138
912.761875
