cnReach N500 User Guide

Technical Reference

phn-4673_002v000 (March 2018)

3-45

900 MHz Specific Performance Data

900 MHz ISM Throughput Measurements

Measured throughput in UDP. For each radio in the following performance data section throught is

provided for a variety of frame sizes and modulations. And then also for the packet size. Some

definitions:

Frame size: length of the payload frames in the user data

Packet size: configured packet (max payload size) in the radio GUI

Transmit rate: the selected modulation rate in the radio GUI. This refers to the RF signaling rate

Radio RF throughput: the capacity as displayed in the RF throughput diagnostics tool

Throughput shown in table: capacity as measured using UDP traffic by a JSDU handheld test set.

256 bytes packet size

Frame size [bytes]

Transmit

Rate [kbps]

Radio RF

Throughput

[kbps]

64

128

256

512

1024

1280

1518

4419 1414.1 397.8 645.0 1210.0 1296.2 1279.1 1272.4 1193.5

3535 1303.8 418.9 744.3 1044.7 1143.3 1168.3 1184.5 798.1

3535 1303.6 397.6 764.3 954.7 1145.2 1173.3 1181.1 1176.4

2651 1102.2 422.2 693.1 895.4 968.4 995.5 989.8 1004.4

2651 1145.8 518.2 781.5 978.3 1005.1 1026.0 1040.4 1045.4

2121 987.1 428.7 759.0 841.9 868.9 599.7 896.6 904.1

1768 921.3 429.3 709.2 787.2 810.8 834.6 840.7 608.2

1591 840.3 433.6 464.5 719.6 741.5 761.6 767.0 770.3

1061 655.7 441.8 498.8 555.6 572.9 590.3 594.5 598.7

884 581.1 397.3 447.8 497.5 513.6 529.3 534.3 536.2

663 462.5 317.2 356.9 396.9 410.3 422.7 426.3 428.9

530 384.4 263.5 297.1 330.2 341.7 350.0 200.1 200.1

229 180.3 124.0 139.7 156.1 162.0 99.9 163.8 170.0

153 123.6 85.2 96.3 106.0 109.4 99.9 102.4 97.2

114 94.4 62.5 70.0 40.0 81.9 81.9 81.9 72.9

57 47.6 33.6 20.5 41.4 41.0 32.8 41.0 24.3
