cnReach N500 User Guide
Technical Reference
phn-4673_002v000 (March 2018)
3-34
Analog Input
Analog input functions are used to measure voltage and current signals. The most common analog
signals are 1 to 5 Volt and 4 to 20 milliAmp.
Analog Input with True Zero and 6 Volt Range
The maximum measurement error of analog inputs from 0 to 6 Volts is 0.5% across the entire operating
temperature range.
Analog Input with True Zero and 7.5 Volt Range
The maximum measurement error of analog inputs from 0 to 7.5 Volts is 2.5% across the entire
operating temperature range.
Analog Input with 0 to 25 milliAmp Range
The maximum measurement error of analog inputs from 0 to 25 milliAmps is 0.5% across the entire
operating temperature range.
Analog Output
Analog input functions are used to drive equipment to variable positions.
Analog Output with 0 to 24 milliAmp Range
The Analog Output can drive current from 0 to 24 milliAmps. The maximum output error is 0.5% across
the entire operating temperature range.
