L2 Features 126

1. Type the config terminal command into the terminal. Press the Enterkey.

2. Type the scheduler 2 interface gigabitethernet 0/3 sched-algo rr command into the terminal to

create thescheduler 2 on a certain interfaceand to configure the packet scheduling algorithm as

round robin. Press the Enterkey.

3. Type the scheduler 3 interface gigabitethernet 0/5 sched-algo strict-priority command into

theterminal to create thescheduler3 on a certain interface and to configurethe packet

scheduling algorithm as strict scheduling. Press the Enterkey.

4. Type the scheduler 4 interface gigabitethernet 0/6 sched-algo strict-wrr command into the

terminal to create thescheduler 4 on a certain interface and to configure the packet scheduling

algorithm as weighted round robin. Press the Enterkey.

5. Type the queue 8 interface gigabitethernet 0/6 weight 0 command into the terminal to set the

weight to the configured scheduling algorithm.Press the Enterkey.

Note

The weight parametercan only be configured for weighted round robin and strict

weighted round robin algorithms.

6. Type the queue 5 interface gigabitethernet 0/6 weight 50 command into the terminal. Press the

Enterkey.

7. Type the scheduler 5 interface gigabitethernet 0/7 sched-algo wrr command into the terminal.

Press the Enterkey.

8. Type the queue 5 interface gigabitethernet 0/7 weight 30 command into the terminal. Press the

Enterkey.

9. Type the queue 4 interface gigabitethernet 0/7 weight 60 command into the terminal. Press the

Enterkey.

10. Type the shape-template 20 cir 10000 cbs 1024 command into theterminal. Press the Enterkey.

11. Type the queue 2 interface gigabitethernet 0/5 shaper 20 into theterminal. Press the Enterkey.

12. Type the end command into theterminal to go to the Privileged EXEC mode. Press the Enterkey.

13. Type the show scheduler interface gigabitethernet 0/3 into the terminal todisplay the configured

scheduler for interface gi 0/3. Press the Enter key.

14. Type the show scheduler interface gigabitethernet 0/5 command into the terminal. Press the

Enterkey.
