L2 Features 54

12. Type the spanning-tree vlan 20 root secondary command into theterminal to configure a

secondary root switch for VLAN 20. Press the Enterkey.

13. Type interface gigabitethernet 0/1 command into terminal toselect an interface to be configured.

Press the Enterkey.

14. Type the spanning-tree vlan 10 port-priority 0 command into theterminal to configure port

priority for VLAN 10. Press the Enterkey.

15. Type the exit command into the terminal to go back to the global configuration mode. Press the

Enter key

16. Type the interface gigabitethernet 0/2 command into the terminal to select an interface to be

configured. Press the Enterkey.

17. Type the spanning-tree vlan 20 port-priority 240 command into theterminal to configure port

priority for VLAN 20. Press the Enterkey.

Caution

An error message is displayed. Port priority value should be increments

of 16 up to 240.

18. Type the spanning-tree vlan 20 port-priority 240 command into the terminal. Press the Enter key.

19. Type the exit command into the terminal to go back to the global configuration mode. Press the

Enter key

20. Type the spanning-tree vlan 10 forward-time 30 command into theterminal to configure

theforwarding-delay time. Press the Enter key.

21. Type the spanning-tree vlan 10 max-age 30 into theterminal to configure the maximum age. Press

the Enter key.

22. Type the spanning-tree vlan 10 hello-time 5 command into theterminal to configure the hello time.

Press the Enterkey.

23. Type the interface gigabitethernet 0/1 command into theterminal to select an interface to be

configured. Press the Enter key.

24. Type the spanning-tree link-type point-to-point command into theterminal to specify the link

type, for a rapid transition. Press the Enter key.

25. Type the spanning-tree link-type shared command into theterminal. Press the Enter key.

26. Type the spanning-tree vlan 10 cost 1000 command into theterminal to specify the interface cost.

Press the Enter key.

27. Type the end command into the terminal to go back to the Privileged EXEC mode. Press the

Enterkey.

28. Type the show spanning-tree vlan 10 command into theterminal to display the PVRST

configurations and status. Press the Enter key.
