L2 Features 121

10. Type the exit command into the terminal to go back to the configuration mode. Press the

Enterkey.

11. Type the class-map 13 command into the terminal to add a class map ID and to go to the config-

cls-map mode. Press the Enterkey.

12. Type the match access-group ip-access-list 1002 command into the terminal to associate theIP

ACL 1002 to class map 13. Press the Enterkey.

13. Type the set class 13 command into the terminal to set the traffic class. Press the Enterkey.

14. Type the exit command into the terminal to go back to the configuration mode. Press the Enter

key.

15. Type the policy-map 13 command into the terminal to create a policy map with ID=13 and to go to

the config-ply-map mode. Press the Enter key.

16. Type the set meter 1 command into the terminal to specify the policy meter to be applied by the

policy to the class of traffic. Press the Enterkey.

17. Type the set meter 1 exceed-action cos-transmit-set 7 violate-action drop command into the

terminal to configure the action to be performed on the packet, the VLAN priority of the outgoing

packets as 7 and the action to be performed on the packet, when the packets are found to be out

of profile as drop. Press the Enterkey.

18. Type the set policy class 13 command into the terminal to set class for policy. Press the Enterkey.

19. Type the exit command into the terminal to go back to the configuration mode. Press the

Enterkey.

20. Type the set meter-stats enable meter-id 1 command into theterminal. Press the Enterkey.

Note

Starting with version 2.1, this command has been removed. The meters stats are now

enabled by default.

21. Type the end into the terminal to go to the Privileged EXEC mode. Press the Enterkey.

22. Type the show access-lists ip 1002 command into the terminal to display the configured IP access

list. Press the Enterkey.
