SD675650 ISSUE 6 M172 DELTA
N
L
Customer interface
Connections wiin
e Delta terminal box
8
9
Pool pump starter
Customer’s external pump/
filter time clock
“Pool Pump Run” demand – terminals 8/9
For control of e water pump at pumps rough e Delta pool water circuit.
If is pool water pump runs continuously, ese terminals do not need to
be used. If is pool water pump is controlled NOT to run continuously, ese
terminals must be used to start e pump when it would oerwise be off.
These are volt free contacts rated at 0.5A at 230V. Contacts close when e
Delta requires pool water flow.
Where e pool water pump is controlled by a time clock (supplied by e
oers) e Delta control system can override “pump off” periods to ensure
pool water flows rough e Delta when required. Using ese terminals, in
conjunction wi e pool pump time clock, e pool filtration pump will run
when:
a. A “pump on” period has been set by e time clock for filtration purposes.
b. The Delta needs to provide heat recovery to e pool water or e pool
requires supplementary heating.
If e pool water pump runs continuously ese contacts do not need to be
used.
Swimming pool filtration pump time clock
If e pool filtration pump is controlled by its own time clock (not part of Delta),
at time clock should be set as required, wi e addition of sampling periods
to allow e Delta to check and maintain e pool water temperature.
If e pool water temperature is below e set temperature during e sampling
period, e Delta unit will continue to run e filtration pump to allow e pool to
be heated until e set temperature is reached. (See User Settings).
The Delta control system may override e pool filtration pump time clock.
2
1
2
4
2
3
2
2
2
1
20
1
9
1
8
17
1
6
1
5
14
1
3
1
2
1
1
1
0
9
8
7
6
5
4
3
Night time pool
pump run period
Typical day time
sampling period
