SD675650 ISSUE 6 M172 DELTA
3.3 FRESH AIR AND EXHAUST AIR
Fresh air in
Exhaust air out
Controls
Always use flexible
connections from adequately
supported duct work to e Delta
Note
Duct work should be heavily
insulated if e Delta is used
in a plenum chamber application.
i.e. If e Delta is istalled in a plant
room wiout ducting from e pool hall
to e Delta air inlet.
Front of Delta
Separator panel
Minimum distance
2m (6 feet)
Wall
Fresh air in
Exhaust air
out
Plan view of Delta
See note 5
If is distance to e
obstruction (hedge or wall)
is less an 7m (20 feet),
en a full height separator
panel may be required to
prevent recirculation
Notes
1. Ensure duct work pressure drop including all inlet/outlet grilles does not
exceed resistance given in data sheet, section 5.0.
2. Every effort must be made to prevent re-circulation of exhaust air back
into e fresh air inlet.
3. Ensure fresh air inlet does not become blocked by debris (leaves, grass
cuttings, etc).
4. If unit is located in a plant room at pool hall air temperatures any ambient
air ducting must be heavily insulated.
5. Ensure flexible couplings are used to seal e ambient suction and
discharge adapters from each oer to prevent cold air from entering e
plant room.
