63
SD675650 ISSUE 6 M172 DELTA
flow °C 65 60 55 50 45
DELTA 1 Upgraded air heating capacity kW 23.3 20.0 16.7 13.3 10.0
Available for fabric losses, mode A, -5°C kW 17.6 14.3 10.9 7.6 4.3
Pool water heating capacity kW 16.1 13.8 11.5 9.2 6.9
Recommended boiler capacity kW 39.4 33.8 28.2 22.5 16.9
LPHW flow rate L/min 40 40 40 40 40
Return temperature air heating only °C 56.6 52.8 49.0 45.2 41.4
Return temperature pool heating only °C 59.2 55.1 50.9 46.7 42.5
Return temperature bo heating °C 50.9 47.9 44.9 41.9 38.9
flow °C 65 60 55 50 45
DELTA 2 Upgraded air heating capacity kW 25.7 22.0 18.3 14.7 11.0
Available for fabric losses, mode A, -5°C kW 19.5 15.9 12.2 8.5 4.9
Pool water heating capacity kW 16.1 13.8 11.5 9.2 6.9
Recommended boiler capacity kW 41.8 35.8 29.8 23.9 17.9
LPHW flow rate L/min 40 40 40 40 40
Return temperature air heating only °C 55.8 52.1 48.4 44.7 41.1
Return temperature pool heating only °C 59.2 55.1 50.9 46.7 42.5
Return temperature bo heating °C 50.0 47.2 44.3 41.4 38.6
flow °C 65 60 55 50 45
DELTA 4 Upgraded air heating capacity kW 29.2 25.0 20.8 16.7 12.5
Available for fabric losses, mode A, -5°C kW 21.8 17.6 13.4 9.3 5.1
Pool water heating capacity kW 23.1 19.8 16.5 13.2 9.9
Recommended boiler capacity kW 52.3 44.8 37.3 29.9 22.4
LPHW flow rate L/min 50 50 50 50 50
Return temperature air heating only °C 56.6 52.8 49.0 45.2 41.4
Return temperature pool heating only °C 58.4 54.3 50.3 46.2 42.2
Return temperature bo heating °C 50.0 47.2 44.3 41.4 38.6
flow °C 65 60 55 50 45
DELTA 6 Upgraded air heating capacity kW 35.0 30.0 25.0 20.0 15.0
Available for fabric losses, mode A, -5°C kW 24.8 19.8 14.8 9.8 4.8
Pool water heating capacity kW 23.1 19.8 16.5 13.2 9.9
Recommended boiler capacity kW 58.1 49.8 41.5 33.2 24.9
LPHW flow rate L/min 58 58 58 58 58
Return temperature air heating only °C 56.4 52.6 48.8 45.1 41.3
Return temperature pool heating only °C 59.3 55.1 50.9 46.7 42.6
Return temperature bo heating °C 50.6 47.7 44.7 41.8 38.8
flow °C 65 60 55 50 45
DELTA 8 Upgraded air heating capacity kW 40.8 35.0 29.2 23.3 17.5
Available for fabric losses, mode A, -5°C kW 27.8 21.9 16.1 10.3 4.4
Pool water heating capacity kW 23.1 19.8 16.5 13.2 9.9
Recommended boiler capacity kW 63.9 54.8 45.7 36.5 27.4
LPHW flow rate L/min 63 63 63 63 63
Return temperature air heating only °C 55.7 52.0 48.4 44.7 41.0
Return temperature pool heating only °C 59.7 55.5 51.2 47.0 42.7
Return temperature bo heating °C 50.5 47.5 44.6 41.7 38.8
flow °C 65 60 55 50 45
DELTA 10 Upgraded air heating capacity kW 44.3 38.0 31.7 25.3 19.0
Available for fabric losses, mode A, -5°C kW 28.7 22.4 16.1 9.7 3.4
Pool water heating capacity kW 28.0 24.0 20.0 16.0 12.0
Recommended boiler capacity kW 72.3 62.0 51.7 41.3 31.0
LPHW flow rate L/min 69 69 69 69 69
Return temperature air heating only °C 55.8 52.1 48.4 44.7 41.1
Return temperature pool heating only °C 59.2 55.0 50.8 46.7 42.5
Return temperature bo heating °C 50.0 47.1 44.3 41.4 38.6
flow °C 65 60 55 50 45
DELTA 12 Upgraded air heating capacity kW 49.0 42.0 35.0 28.0 21.0
Available for fabric losses, mode A, -5°C kW 31.0 24.0 17.0 10.0 3.0
Pool water heating capacity
kW 28.0 24.0 20.0 16.0 12.0
Recommended boiler capacity kW 77.0 66.0 55.0 44.0 33.0
LPHW flow rate L/min 73 73 73 73 73
Return temperature air heating only °C 55.4 51.8 48.1 44.5 40.9
Return temperature pool heating only °C 59.5 55.3 51.1 46.9 42.6
Return temperature bo heating °C 49.9 47.0 44.2 41.4 38.5
flow °C 65 60 55 50 45
DELTA 14 Upgraded air heating capacity kW 92.2 79.1 65.9 52.7 39.5
Available for fabric losses, mode A, -5°C kW 58.9 45.8 32.6 19.4 6.2
Pool water heating capacity kW 45.5 39.0 32.5 26.0 19.5
Recommended boiler capacity kW 137.7 118.1 98.4 78.7 59.0
LPHW flow rate L/min 202 202 202 202 202
Return temperature air heating only °C 58.5 54.4 50.3 46.3 42.2
Return temperature pool heating only °C 61.8 57.2 52.7 48.2 43.6
Return temperature bo heating °C 55.2 51.6 48.0 44.4 40.8
flow °C 65 60 55 50 45
DELTA 16 Upgraded air heating capacity kW 105.0 90.0 75.0 60.0 45.0
Available for fabric losses, mode A, -5°C kW 65.1 50.1 35.1 20.1 5.1
Pool water heating capacity kW 45.5 39.0 32.5 26.0 19.5
Recommended boiler capacity kW 150.5 129.0 107.5 86.0 64.5
LPHW flow rate L/min 202 202 202 202 202
Return temperature air heating only °C 57.5 53.6 49.7 45.7 41.8
Return temperature pool heating only °C 61.8 57.2 52.7 48.2 43.6
Return temperature bo heating °C 54.3 50.8 47.4 43.9 40.4
5.2 LPHW HEATING DATA - DELTA WITH UPGRADED AIR HEATER
(WHERE MODEL NUMBER INCLUDES +E)
Data based on air 30°C, pool water 28°C.
