SD675650 ISSUE 6 M172 DELTA
DELTA SYSTEM OWNER INSTALLATION MANUAL
5.1 LPHW HEATING DATA - DELTA WITH STANDARD AIR HEATER
flow °C 80 70 60 50 45
DELTA 1 Standard air heating capacity kW 20.0 16.0 12.0 8.0 6.0
Available for fabric losses, mode A, -5°C kW 14.3 10.3 6.3 2.3 0.3
Pool water heating capacity kW 23.0 18.4 13.8 9.2 6.9
Recommended boiler capacity kW 43.0 34.4 25.8 17.2 12.9
LPHW flow rate L/min 28 28 28 28 28
Return temperature air heating only °C 69.8 61.8 53.9 45.9 41.9
Return temperature pool heating only °C 68.2 60.6 52.9 45.3 41.5
Return temperature bo heating °C 58.0 52.4 46.8 41.2 38.4
flow °C 80 70 60 50 45
DELTA 2 Standard air heating capacity kW 22.0 17.6 13.2 8.8 6.6
Available for fabric losses, mode A, -5°C kW 15.9 11.5 7.1 2.7 0.5
Pool water heating capacity kW 23.0 18.4 13.8 9.2 6.9
Recommended boiler capacity kW 45.0 36.0 27.0 18.0 13.5
LPHW flow rate L/min 28.0 28 28 28 28
Return temperature air heating only °C 68.7 61.0 53.2 45.5 41.6
Return temperature pool heating only °C 68.2 60.6 52.9 45.3 41.5
Return temperature bo heating °C 57.0 51.6 46.2 40.8 38.1
flow °C 80 70 60 50 45
DELTA 4 Standard air heating capacity kW 25.0 20.0 15.0 10.0 7.5
Available for fabric losses, mode A, -5°C kW 17.6 12.6 7.6 2.6 0.1
Pool water heating capacity kW 33.0 26.4 19.8 13.2 9.9
Recommended boiler capacity kW 58.0 46.4 34.8 23.2 17.4
LPHW flow rate L/min 35.0 35 35 35 35
Return temperature air heating only °C 69.8 61.8 53.9 45.9 41.9
Return temperature pool heating only °C 66.5 59.2 51.9 44.6 40.9
Return temperature bo heating °C 56.2 51.0 45.7 40.5 37.9
flow °C 80 70 60 50 45
DELTA 6 Standard air heating capacity kW 30.0 24.0 18.0 12.0 9.0
Available for fabric losses, mode A, -5°C kW 19.8 13.8 7.8 1.8 -1.2
Pool water heating capacity kW 33.0 26.4 19.8 13.2 9.9
Recommended boiler capacity kW 63.0 50.4 37.8 25.2 18.9
LPHW flow rate L/min 39 39 39 39 39
Return temperature air heating only °C 69.0 61.2 53.4 45.6 41.7
Return temperature pool heating only °C 67.9 60.3 52.7 45.1 41.4
Return temperature bo heating °C 56.8 51.5 46.1 40.7 38.1
flow °C 80 70 60 50 45
DELTA 8 Standard air heating capacity kW 35.0 28.0 21.0 14.0 10.5
Available for fabric losses, mode A, -5°C kW 21.9 14.9 7.9 0.9 -2.6
Pool water heating capacity kW 33.0 26.4 19.8 13.2 9.9
Recommended boiler capacity kW 68.0 54.4 40.8 27.2 20.4
LPHW flow rate L/min 42 42 42 42 42
Return temperature air heating only °C 68.1 60.4 52.8 45.2 41.4
Return temperature pool heating only °C 68.7 61.0 53.2 45.5 41.6
Return temperature bo heating °C 56.8 51.4 46.1 40.7 38.0
flow °C 80 70 60 50 45
DELTA 10 Standard air heating capacity kW 38.0 30.4 22.8 15.2 11.4
Available for fabric losses, mode A, -5°C kW 22.4 14.8 7.2 -0.4 -4.2
Pool water heating capacity kW 40.0 32.0 24.0 16.0 12.0
Recommended boiler capacity kW 78.0 62.4 46.8 31.2 23.4
LPHW flow rate L/min 49 49 49 49 49
Return temperature air heating only °C 68.9 61.1 53.3 45.6 41.7
Return temperature pool heating only °C 68.3 60.6 53.0 45.3 41.5
Return temperature bo heating °C 57.2 51.7 46.3 40.9 38.2
flow °C 80 70 60 50 45
DELTA 12 Standard air heating capacity kW 42.0 33.6 25.2 16.8 12.6
Available for fabric losses, mode A, -5°C kW 24.0 15.6 7.2 -1.2 -5.4
Pool water heating capacity
kW 40.0 32.0 24.0 16.0 12.0
Recommended boiler capacity kW 82.0 65.6 49.2 32.8 24.6
LPHW flow rate L/min 53 53 53 53 53
Return temperature air heating only °C 68.6 60.9 53.2 45.5 41.6
Return temperature pool heating only °C 69.2 61.3 53.5 45.7 41.8
Return temperature bo heating °C 57.8 52.3 46.7 41.1 38.3
flow °C 80 70 60 50 45
DELTA 14 Standard air heating capacity kW 85.0 68.0 51.0 34.0 25.5
Available for fabric losses, mode A, -5°C kW 51.7 34.7 17.7 0.7 -7.8
Pool water heating capacity kW 65.0 52.0 39.0 26.0 19.5
Recommended boiler capacity kW 150.0 120.0 90.0 60.0 45.0
LPHW flow rate L/min 115 115 115 115 115
Return temperature air heating only °C 69.4 61.5 53.6 45.8 41.8
Return temperature pool heating only °C 71.9 63.5 55.1 46.8 42.6
Return temperature bo heating °C 61.3 55.0 48.8 42.5 39.4
flow °C 80 70 60 50 45
DELTA 16 Standard air heating capacity kW 90.0 72.0 54.0 36.0 27.0
Available for fabric losses, mode A, -5°C kW 50.1 32.1 14.1 -3.9 -12.9
Pool water heating capacity kW 65.0 52.0 39.0 26.0 19.5
Recommended boiler capacity kW 155.0 124.0 93.0 62.0 46.5
LPHW flow rate L/min 115 115 115 115 115
Return temperature air heating only °C 68.8 61.0 53.3 45.5 41.6
Return temperature pool heating only °C 71.9 63.5 55.1 46.8 42.6
Return temperature bo heating °C 60.7 54.5 48.4 42.3 39.2
Data based on air 30°C, pool water 28°C.
