SD675650 ISSUE 6 M172 DELTA
5.0 DATA SHEET
Specifications Units
DT1A
DT1B
DT2A
DT2B
DT4A
DT4B
DT6A
DT6B
DT8B DT10B DT12B DT14B DT16B
DEHUMIDIFICATION DUTY
Heat pump dehumidification 28°C/60%, min. fresh air L/h 4.5 5·5 6.0 8.0 10.0 12.0 14.0 28.0 30.0
Total at 18°C dew point (summer) max. fresh air L/h 6.5 7.3 9.0 12.0 15.0 18.0 21.0 41.0 48.0
Total at 7°C dew point (winter) mid. fresh air L/h 9.5 10.7 12.1 16.1 20.1 24.2 28.2 55.0 60.5
VDI 2089 L/h 7.6 8.2 9.5 12.6 15.8 19.0 22.2 42.5 51.4
Total DH + VDI 2089 at12.5°C dew point – summer L/h 9.8 10.9 12.5 16.6 20.8 25.0 29.2 56.5 62.4
HEAT TO AIR
Heat pump heat recovery – Mode A (priority to water) kW 1.3 1.5 1.4 1.5 1.6 2.0 2.5 6.0 7.0
Heat pump heat recovery – Mode B (priority to air) kW 3.8 4.9 5.1 6.6 8.0 10.0 12.1 30.0 35.0
Standard LPHW at 80°C flow - see section 5.1 kW 20 22 25 30 35 38 42 85 90
Upgraded LPHW at 55°C flow - see section 5.2 kW 17 19 21 26 30 32 36 72 77
Total – std. LPHW + Mode A/Mode B heat recovery kW 21.3/23.8 23.5/26.9 26.4/30.1 31.5/36.6 36.6/43.0 40.0/48.0 44.5/54.1 91.0/115.0 97.0/125.0
Available for fabric losses, std. LPHW, Mode A, -5°C kW 14.3 15.9 17.6 19.8 21.9 22.4 24.0 51.7 50.1
Available for fabric losses, upg. LPHW, Mode A, -5°C kW 11.3 12.6 13.9 15.3 16.7 16.7 17.7 39.0 36.6
HEAT TO POOL WATER
Heat pump heat recovery – Mode A (priority to water) kW 4.0 5.5 5.8 8.0 10.0 12.5 15.0 35.0 43.0
Heat pump heat recovery – Mode B (priority to air) kW 1.7 2.2 2.3 3.0 3.7 4.6 5.5 12.0 14.0
LPHW at 80°C flow - see section 5.1 kW 23 23 33 33 33 40 40 65 65
LPHW at 55°C flow - see section 5.2 kW 11 11 16 16 16 20 20 32 32
Total – LPHW + Mode A/Mode B heat recovery kW 27.0/24.7 28.5/25.2 38.8/35.3 41.0/36.0 43.0/36.7 52.5/44.6 55.0/45.5 100.0/77.0 108.0/79.0
Flow rate – pool water ± 10% L/minute 31.5 31.5 38.0 40.0 40.0 54.0 54.0 100.0 100.0
Pressure drop at rated flow m/kPa 1.4/13.7 1.4/13.7 2.5/24.5 2.5/24.5 2.5/24.5 3.5/34.3 3.5/34.3 3.5/34.3 3.5/34.3
Maximum working pressure bar 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5
Plate heat exchanger pool water flow meter setting L/minute 17.5 17.5 24.0 24.0 24.0 29.0 29.0 - -
COOLING DUTY
Mode A/B Mode A/B Mode A/B Mode A/B Mode A/B Mode A/B Mode A/B Mode A/B Mode A/B
Cooling duty – sensible kW 2.0/- 2.5/- 2.9 3.9 4.7 5.9 7.1 13.0 15.0
Cooling duty – total kW 3.0/- 4.0/- 4.2 5.5 6.7 8.4 10.1 23.0 28.0
LPHW DATA
Rec. min. boiler capacity (standard LPHW at 80°C) kW 43 45 58 63 68 78 82 150 155
Rec. min. boiler capacity (upgraded LPHW at 55°C) kW 28 30 37 42 46 52 56 104 109
Flow rate – standard LPHW L/minute 28 28 35 39 42 49 53 115 115
Flow rate – upgraded LPHW L/minute 40 40 50 58 63 69 73 202 202
Pressure drop at rated flow rate m/kPa 2.0/19.6 2.0/19.6 2.5/24.5 2.5/24.5 2.5/24.5 2.8/27.4 2.8/27.4 4.0/39.2 4.0/39.2
Maximum working pressure bar 6 6 6 6 6 6 6 6 6
Plate heat exchanger LPHW flow meter setting L/minute 14 14 19 19 19 23 23 - -
ELECTRICAL
Total power consumed – nominal kW 2.6 2.9 2.9 3.4 4.4 5.9 7.4 12.3 17.0
Minimum supply capacity (FLA) 230V/1N/50Hz A 22 24 25 33 - - - - -
Minimum supply capacity (FLA) 400V/3N/50Hz A 10 11 13 16 19 22 23 38 47
Maximum supply fuse 230V/1N/50Hz A 32
32 40 50 - - - - -
Maximum supply fuse 400V/3N/50Hz A 16 20 20 25 25 32 32 50 63
MAIN FAN DATA – VARIABLE SPEED
Design air flow – supply volume m³/h 2500 2600 3000 4000 5000 6000 7000 10000 12000
Design external static pressure Pa 150 150 200 200 200 250 250 250 250
Maximum external static pressure standard LPHW Pa 200 200 700 450 800 800 500 800 450
Maximum external static pressure upgraded LPHW Pa 180 180 670 410 740 760 450 750 400
Design running amps – 230V/1N fans A 3.5 3.5 2.4 3.1 - - - - -
Design running amps – 400V/3N fans A - - 0.9 1.1 1.9 2.6 4.0 3.7 6.4
FLA – 230V/1N fans A 5.2 5.2 6.8 6.8 - - - - -
FLA – 400V/3N fans A - - 4.0 4.0 4.0 5.8 5.8 8.0 8.0
EXHAUST FAN DATA – VARIABLE SPEED
Design air flow – summer maximum fresh air volume m³/h 1200 1300 1500 2000 2500 3000 3500 6700 8000
Air flow – winter maximum fresh air volume m³/h 600 650 750 1000 1250 1500 1750 3350 4000
Air flow – minimum fresh air volume m³/h 120 130 150 200 250 300 350 670 850
Design external static pressure Pa 50 50 80 100 100 150 150 150 150
Max external static pressure Pa 300 290 280 200 110 500 500 500 320
Design running amps – 230V/1N fans A 0.9 0.9 1.7 2.3 3.0 - - - -
Design running amps – 400V/3N fans A - - - - - 1.0 1.4 2.7 3.7
FLA – 230V/1N fans A 3.0 3.0 3.0 3.0 5.2 - - - -
FLA – 400V/3N fans A - - - - - 4.0 4.0 6.2 6.2
PART F – ACTUAL SFP AT DESIGN CONDITION W/L/s 1.27 1.23 0.94 0.89 1.23 1.35 1.64 1.47 2.07
COMPRESSOR DATA
Nominal power consumed kW 1.7 2.0 2.1 2.4 2.7 3.6 4.2 8.2 10.1
Nominal RLA – 230V/1N/50Hz A 10.2 12.4 12.4 12.8 - - - - -
Starting current – 230V/1N/50Hz A 62 62 62 103 - - - - -
Starting current – 230V/1N/50Hz (wi so start) A 28 28 28 34 - - - - -
Nominal RLA – 400V/3N/50Hz A 3.2 4.8 4.8 4.7 5.1 6.4 8.9 14.1 22.4
Starting current – 400V/3N/50Hz A 38 30.5 30.5 48 48 48 101 102 174
Starting current – 400V/3N/50Hz (wi so start) A 15 16 16 25 25 25 34 34 41
GENERAL DATA
HERMETIC REFRIGERATION SYSTEM
Refrigerant charge – R407C kg 3.0 3.0 6.0 7.8 7.8 9.0 8.0 21.5 22.5
Weight – unpacked kg 300 310 350 360 370 410 460 954 1020
For accurate project sizing consult e Danerm Group or your local representative 1mm water gauge = 9.8Pa
Mode A: heat recovery biased to pool water when pool water temperature not satisfied 1m head = 9.8kPa
Mode B: heat recovery biased to pool hall air when pool water temperature satisified 1L/minute = 0.22gallon/minute (Imperial)
R407c global warming potential (GWP): 1774
