SD675650 ISSUE 6 M172 DELTA
3.6 ELECTRICAL CONNECTIONS
The volt free terminals are accessible by removing e touchscreen access
panel. The panel has been designed to hang on e mains in terminal service
panel when not fixed in e normal operating position.
There are two cable access holes in e side of e machine. The access panels
can be removed to make it easier to feed e cables into e Delta.
Use e lower hole for cable access to e mains in terminals.
Use e upper hole for cable access to volt free and customer terminals.
TOUCHSCREEN USER
INTERFACE
POWER LIGHT
ACCESS PANEL
ACCESS PANEL
