49-2000930 Rev. 3 5
Controls
USING THE HOOD: Controls
1. Rangehood Control Panel: The control panel
is located on the front of the canopy. The position
and function of each control button are noted below.
2. Fan On/Off Button: On/Off switch for the fan.
The fan can be operated by pressing any of the fan
setting buttons. Hold for 3 seconds to activate Delay
Off feature, which automatically turns the fan off
after 15 minutes.
3. Fan Setting Button: Speed control for the
fan. Fan speed is powered by QuietBoost™
Technology. This unique technology is designed
to minimize ventilation noise and enhance motor
efficiency for a peacefully-quiet, odor-free kitchen.
Press LOW for LOW speed, MED for MEDIUM
speed, and HIGH for HIGH speed. Press and hold
the HIGH button for 3 seconds to activate the
BOOST speed that will run for 10 minutes.
On Remote, press Up to increase fan speed, press
Down to decrease fan speed, including Boost.
4. Light Button: On/Dim/Off switch for the LED
lights. Press the Light button to turn the lights on,
again to set the lights to dim setting, and again to
turn the lights off.
5. Chef Connect: This is a Bluetooth
®
pairing feature
for use with other compatible Chef Connect enabled
products on a cooktop or range. When the device is
paired, the light and fan will turn ON at the Default
Sync Settings upon receiving a command from the
range or cooktop. It will remain ON at that setting until
the user changes it. To pair devices, hold down the
Chef Connect button for 3 seconds. To turn it back
off, hold the button down for another 3 seconds, see
the Chef Connect section for details.
6. IR Sensor: Remote control reciever when used
with Remote Control Kit (UXRC1).
7. Wi-Fi: Hold down the Light and Chef Connect
buttons for 3 seconds to activate the Wi-Fi. The
Wi-Fi light turns on when connected
, see the Wi-Fi
Connect section for details
. On Remote, press Wi-Fi
to toggle Wi-Fi function.
8. Delay Off (Remote only): Press and hold
Delay Off to toggle Delay Off function.
Heat Sensor
Your hood is equipped with a HEAT SENSOR
thermostat. This thermostat is a device that will turn on
or speed up the blower if it senses excessive heat above
the cooking surface.
Ŷ,IEORZHULV2IILWWXUQVEORZHU2QWR0HGVSHHG
Ŷ,IEORZHULV2QDWDORZHUVSHHGVHWWLQJLWWXUQV
blower up to Med speed.
When the temperature level drops to normal, the blower
will return to its original setting.
326541
7
8
Remote Control
4
7
2
5
3
