12 49-7000313 Rev. 0
INSTALLATION PREPARATION
Installation Preparation
PARTS PROVIDED
Locate the parts packed with the hood.
HARDWARE PACKAGE
Locate and check contents.
Top Damper
761Dia28
Grease Drip Trays
Motor
Hood Body
Metal Installation Bracket
3 Baffle Filters
(QTY: 2) 3/16” dry wall
anchors with screws. Used
for hood bottom mounting
screw holes. Use 5/16" drill
for pilot hole.
(QTY: 4) M4 screws.
Used to mount motor
(QTY: 6) 8 x 1-3/4 AB
screw. Used to mount the
installation bar. Use 1/8"
drill for pilot hole.
(QTY: 4) 2.9mm x 6mm
PZ screws. Used to
attach the damper
A B
C
D
