15
KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80
Fig. 21 - Remove the screws Fig. 22 - Remove the deector
9 FUEL
• The allowed fuel is firewood and its derivatives (lignite blocks, compressed sawdust, etc.) with a maximum water content of 20%.
• To obtain good firewood, it must be seasoned outside for at least 2 years in a place protected from the weather.
• If the wood is purchased it must fulfil standard UNI-EN-14961-2 namely UNI EN ISO 17225-2 (class A1).
Using damp wood or scraps of bark results in the formation of creosote in the ducts and in the hearth. The heat
output of damp wood is much lower than the heat output of dry wood and pollutes a lot more.
• To know the lenght of wood log to use, check the dimensions of stove combustion chamber.
• Here following some information about the quality of different type of woods:
TYPE OF WOOD QUALITY % PERFORMANCE
Oak Excellent 100
Hornbeam Excellent 100
Ash Very good 92
Maple Very good 91
Birch Good 89
Elm Good 84
Beech Good 80
Willow Sufficient 71
Spruce Sufficient 70
Red deal Fair 67
Larch Fair 66
Lime Worst 57
Poplar Worst 50
10 ROUTINE MAINTENANCE
10.1 INTRODUCTION
For a long working life of the stove, have a periodic cleaning of the stove as described in the following paragrafs.
• Fume outlet pipes (fume conduit + chimney flue + chimney pot) must always be cleaned, scrubbed and checked by an autho-
rized technician in compliance with local regulations, with the instructions of the manufacturer and those of your insurance
company.
• If there are no local regulations and no instruction from your insurance company, it is necessary to have your fume pipe, chim-
ney flue and chimney pot cleaned at least once a year.
• It is also necessary to have the combustion chamber, motors and fans cleaned and to have the gaskets and the electronical
elements (if there are) checked at least once a year.
All these operations must be planned in time with your Autorized Technical Assistance Service.
