KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80
26
• Remove the cast iron/ceramic glass top.
• Undo the screw of the profile that locks the refractory material in place (see Fig. 66).
• Remove the steel profile (see Fig. 67).
• Remove the broken refractory material and replace it (see Fig. 68 Fig. 69 Fig. 70).
Use exclusively original spare parts.
7.11 REPLACING THE STAINLESS STEEL TOP
In the event of a replacement, proceed as follows:
Fig. 71 - Screw removal Fig. 72 - Screw removal Fig. 73 - Remove the top
• Remove the side panels (see relative chapter).
• Loosen the 10 screws along the entire perimeter of the top without removing them (see Fig. 71 and Fig. 72).
• Remove the stainless steel top (see Fig. 73).
7.12 REPLACING THE DOORS
In the event of a replacement, proceed as follows:
Fig. 74 - Undo the screw Fig. 75 - Remove the door
• Loosen the door locking screw (see Fig. 74).
• Remove the door by releasing it from the pins (see Fig. 75).
