KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80
15
coatings etc...) as described in Fig. 15 e Fig. 16].
• If highly flammable materials (curtains, carpets, etc...), all these distances must be increased of 1 meter.
• In some countries also loadbearing masonry walls are considered flammable.
• If the floor is made up of flammable material, an unburnt material cover must be realized (steel plate, refractory, marble...). For
cover dimensions see Fig. 15 e Fig. 16].
• Check if the floor has a proper load capacity. If the existing manufacture does not reach this requirement, proper measures
must be taken (for example a load distribution plate).
• If air recirculation hoods are used, they must be suitable to be used over the stove and must be placed at a distance of minimum
75 cm.
6.4 LEVELLING KOOK 60
All stove models are endowed with adjustable feet which allow a plumbed appliance and a better adaptability for recess.
• Remove the drawer.
• Adjust the feet (see Fig. 17).
• You can also adjust the plinth profile: loosen the screws, lower the profile and then lock the screws at the desired height (see
Fig. 18).
Fig. 17 - Feet adjustment: Kook 60 Fig. 18 - Plinth prole adjustment: Kook 60
You can also adjust the wood drawer plinth, so that it is aligned with the side plinths.
Proceed as follows:
• The inside of the drawer (see Fig. 19) has 3 holes containing 2 screws: remove the lower screw and loosen the upper one (see
Fig. 20).
• Slide the drawer profile up to the same height of the side plinths (see Fig. 21).
• Tighten the screws.
Fig. 19 - Wood drawer Fig. 20 - Remove/loosen screws Fig. 21 - Prole adjustment
Pay attention to models recessed in a marble top. If the stove needs to be removed from the furniture, the feet
must be lowered till the cooktop is under the marble top level and now the appliance can be removed.
6.5 LEVELLING KOOK 80 - KOOK 90 - SMART 60 - SMART 80
All stove models are endowed with adjustable feet which allow a plumbed appliance and a better adaptability for recess.
• Remove the drawer.
• Adjust the feet (see Fig. 22).
