KOOK60 - KOOK80 - KOOK90 - SMART60 - SMART80 - FRIDA 80
16
Fig. 22 - Feet adjustment: Kook 80 - Kook 90 - Smart 60 - Smart 80
Pay attention to models recessed in a marble top. If the stove needs to be removed from the furniture, the feet
must be lowered till the cooktop is under the marble top level and now the appliance can be removed.
6.6 ASSEMBLY OF DOOR HINGED TO LEFT KOOK 60
The hinges on the fire door can be moved to the other side if required.
Fig. 23 - Remove the brackets Fig. 24 - Remove the pin Fig. 25 - Insert the pin the other way round
• Remove the fire door (see REPLACING THE DOORS a pag. 26).
• Remove the brackets, undoing the 4 x CH8 screws (see Fig. 23).
• Remove the brass pin (see Fig. 24) and insert it the other way round (see Fig. 25).
Fig. 26 - Fix the upper bracket Fig. 27 - Fix the lower bracket
• Fix the brackets on the right side with the 4 x CH 8 screws (see Fig. 26 and Fig. 27).
• NB: make sure that the brackets are in the correct position.
