BZBGEAR BG-COMMANDER-ULTRA PRODUCT MANUAL
Introduction
The BG-COMMANDER-ULTRA integrates a 4K HDMI switcher with a PTZ joystick
controller. Supporting resolutions up to 4K2K@60Hz with both HDR and SDR
capabilities, this device ensures superior video quality and color accuracy. It
adheres to HDMI 2.0 standards with an 18Gbps bandwidth, offering secure content
protection through HDCP 1.4/2.2. Equipped with 5 HDMI inputs, 4 HDMI outputs, 2
XLR audio inputs, and versatile control ports (RS-232, RS-422, Ethernet), this unit
delivers extensive connectivity and flexibility. A standout feature is its embedded
video mixer, which allows seamless transitions like wipe, dissolve, and DVE.
The device also supports LPCM audio, with analog stereo output via XLR, ensuring
top-tier audio management. For camera control, it enables precise remote
adjustments using VISCA, Pelco-D, and Pelco-P protocols over IP and serial
connections. The front board offers intuitive navigation between PTZ and switcher
modes, managing up to four full-view outputs and a multi-view output. Additionally,
the on-screen display (OSD) menu provides easy access to detailed settings and
firmware updates via USB.
Features
● HDMI 2.0 compliant
● HDCP 1.4/2.2 compliant
● Supports HDR for both inputs or outputs and HDR to SDR conversion.
● 4x HDMI 2.0 inputs and 1x HDMI AUX input
● 4x HDMI 2.0 outputs support 1 multi-view output and 3 full-view outputs
● Resolutions support up to 4K2K@60Hz (4:4:4 8bits).
● Supports remote control of multiple camera settings such as pan, tilt, zoom, iris,
focus, shutter, and white balance
● Supports seamless, wipe, DVE, and dissolve switching on full view outputs.
● Supports versatile luma keying, chroma keying, and PIP.
● Supports 4K real-time waveform monitor, vector scope, histogram, and audio bar
indicators on the selected input channel.
● Supports SMPTE and the most popular VESA formats.
● Pure unaltered uncompressed 7.1ch digital HDMI
● Supports RS-422, RS-232, and Ethernet control for the camera
● Supports VISCA, VISCA over IP, Pelco-D, and Pelco-P control protocols
● Supports analog stereo through XLR connectors
● Firmware upgradable through USB port to support new features and technology
enhancements
● USB-C captures up to 1080P60
● RTMP streaming up to 1080P60
● Integrated Micro SDXC card slot for local recording of the PGM feed
Address: 830 National Drive #140, Sacramento, CA 95834, USA · Tel: +1(888)499-9906 · Email: support@bzbgear.com 5
