- Operating water temperature: 5˚C ( 41˚F ) – 35˚C ( 95˚F ).
- For the purposes of recharging the battery, only use the detachable supply unit ( external adaptor
model number: DSS12D-0841000-B / DSS12D-0841000-C / DSS12D-0841000-D / LX084100U )
- Connect the external adaptor to a power source through a residential current device ( RCD ) / a
ground fault circuit interrupter ( GFCI ). If in doubt, consult a qualified electrician.
- Disconnect the robot from the supply mains and make sure the robot is OFF prior to carrying out
regular maintenance – such as cleaning the filter, swivel smoothing-ring, and the areas around the
- Do not attempt to replace the installed rechargeable Li - ion battery pack.
- You should not operate this robot when people and/or pets are present in the water.
- For details regarding battery recycling/disposal, refer to the section “
DO NOT use this robot right after pool-shocking. It is recommended to first leave the pool circulating for at least 24 - 48 hours.
- DO NOT use this robot with another automatic cleaner/cleaner simultaneously in the pool.
adaptor /charging cable or pull the cord to disconnect it from the power source and charging cable.
Pool / spa owners should always exercise extra caution and common sense when utilizing the product.
swivel head turns 180˚, allowing the robot to move in the opposite direction. The robot moves in a generally straight pattern in
Fully charge the robot ( about 6 hrs ) before using it for the first time.
Be sure not to invert the charging cable and ensure both the charging cable and
4. When charging is complete, disconnect the external adaptor from the power source and unplug the
Normally the robot can operate up to 45 minutes on a full charge.
Once the lifespan of the battery reaches its end, refer to section “
Let the robot rest for around 30 to 40 minutes before charging it again.
Pool Preparation
- If there are stones, roots or metal corrosion in contact with the underside of the liner, discard them prior to using the robot.
If necessary, seek assistance from a qualified professional.
- If the liner is brittle, damaged or wrinkled, contact a qualified professional to perform the necessary repairs or perform a liner
replacement prior to using the robot.
- Remove any pool ladder, surface skimmer, and other floating objects from the pool as they may obstruct the movement of
the robot’s float and, consequently, the movement of the robot also.
- If you are using a saltwater pool, make sure all salt are dissolved before placing the robot into the water.
IMPORTANT NOTE: Turn off the filtration system ( as instructed in your filtration manual ) at least 15 minutes prior to
deploying the robot.
OPERATION
WARNING!
- Make sure the robot is off.
- Ensure the charging cable is detached and the charging port is plugged with the protective cap
before the robot is deployed.
1. Bring the robot to the side of your pool. NOTE: Only deploy the robot from the pool side (not the pool corner) and ensure it
is facing outwards as you do so. Unwrap the retrieval cord from the float ( note: there are side notches at the top and bottom
of the stem, as well as a narrow slot at the bottom ).
The correct length of the rope should be equivalent to the distance between the top of the robot and the water level.
NOTE: Excess length may kink the rope and affect performance as a result.
First, align and attach the retrieval cord to the side notches at the top as you wrap the cord around the stem (
3. Slide the power switch to “ ” ( while the robot is still submerged ) – the indicator light will turn on and activate the motor
automatically ( water level covering the sensors at the top of the swivel head ). Let the robot sink to the pool floor and observe
retrieve it and redeploy it while making sure its front/back is facing the pool wall
No light - Power off / no power
Light - Power on
Blinking light - Battery power will be exhausted within 5 - 10 minutes.
4. To retrieve the robot from the pool, attach the hook to a telescopic pole ( not provided ) and use it to retrieve the float, if you
( for Australia / New
5. Slide the power switch OFF. Rinse the robot with fresh water after every use. DO NOT use any detergent.
6. Dry the charging port and pins thoroughly (
Before cleaning the debris compartment, make sure the robot is
clips are secured to the base. A “click” sound will
Before redeploying the robot to the pool, hold onto the wings on the body top cover to sway the robot slightly, to ensure
Float Replacement
Use a screwdriver ( not provided ) to unscrew the 4 screws at on the top cover of the swivel head. Untie the knot on the string
Flap replacement
1. Be sure to clean and dry the areas around the charging port and water sensors after every use to avoid the forming of
2. Battery discharges on its own during storage. Make sure to charge the robot to about 30% to 50% of the battery capacity
• Be sure to drain the water from the robot before storage.
temperature for storage should be 10˚C – 25˚C ( 50˚F – 77˚F ).
- Battery does not charge fully.
Battery operation time is noticeably reduced. Observe and record the run times of the first few operations ( on a full charge ).
could cause sparking and/or short circuit the battery.
Follow section “
2. Use the screwdriver to unscrew the 4 screws located at the bottom of the head to release the
3. Remove out the battery pack to expose the PCBA. To detach the battery connection wire, press
2021/10 : AMAINTENANCE & CLEANING
bwt.com
ENGLISH
5/147
