ANALOGUE OUTPUTS

CONNECTORS: Up to 16 electronically balanced on Phoenix/Combicon removable screw connectors

OUTPUT IMPEDANCE: 40 Ohms balanced, 20 Ohms unbalanced

MAXIMUM OUTPUT LEVEL: +19dBu

FREQUENCY RESPONSE: 20Hz to 20kHz [+0.5/-1dB]

THD: <0.01% [20Hz to 20kHz, +10dBu output]

DYNAMIC RANGE: 108dB typ� [22Hz to 22kHz unweighted]

CROSSTALK: <-75dB

D/A LATENCY: 28/Fs [0�58ms@48k, 0�29ms@96k]

D/A BIT DEPTH: 24-bit

DIGITAL OUTPUTS

CONNECTORS: Up to 16 AES/EBU or S/PDIF on Phoenix/Combicon removable screw connectors

OUTPUT IMPEDANCE: 110 ohm [AES/EBU], 75 ohm [S/PDIF]

SAMPLE RATE: 48kHz or 96kHz

SAMPLE RATE CONVERSION: 8kHz-96kHz

THD+N: <-140dB

LATENCY SRC OFF: 6/Fs [0�13ms@48k, 0�06ms@96k]

LATENCY SRC ON: 60/Fs [1�25ms@48k, 0�63ms@96k]

CONTROL PORTS

NUMBER OF PORTS: 12 inputs and 6 outputs

CONTROL INPUT VOLTAGE: 0 to 4�5v

CONTROL INPUT IMPEDANCE: 4.7kOhms to +5V [2-wire mode] >1MOhm [3-wire mode]

LOGIC OUTPUT VOLTAGE: 0 or +5V unloaded

LOGIC OUTPUT IMPEDANCE: 440 Ohm

LOGIC OUTPUT CURRENT: 10mA source, 60mA sink

WATCHDOG OUTPUT

CONNECTOR: Phoenix/Combicon connector for failsafe control

OPTO OUTPUT CURRENT: 14mA maximum

WITHSTANDING VOLTAGE: 80V maximum [Off]

SERIES IMPEDANCE: 220 Ohms [isolated]

CONTROL NETWORK

CONNECTORS: RJ45 Ethernet connector

MAXIMUM CABLE LENGTH: 100m/328ft on Category 5 cable between device and Ethernet switch

BLU LINK AUDIO NETWORK [BLU-800, 320, 160, 120]

CONNECTORS: 2 x RJ45 Ethernet connectors

MAXIMUM CABLE LENGTH: 100m/328ft on Category 5e cable between devices

LATENCY: 11/Fs [0�23ms@48k, 0�11ms@96k]

PASS THROUGH LATENCY: 4/Fs [0�08ms@48k, 0�04ms@96k]

COBRANET™ AUDIO NETWORK [BLU-80, 32, 800, 320]

CONNECTORS: 2 x RJ45 connectors

MAXIMUM CABLE LENGTH: 100m/328ft on Category 5 cable between device and Ethernet switch

LATENCY: 1�33ms-5�33ms

DANTE/AES67 AUDIO NETWORK [BLU-806 (DA), 326 (DA)]

CONNECTORS: 2 x RJ45 connectors

MAXIMUM CABLE LENGTH: 100m/328ft on Category 5 (100Mbps) or Category 5e/Category 6 (Gigabit) cable

between devices

LATENCY: 0�15ms-5�0ms

AVB AUDIO NETWORK [BLU-805, 325]

CONNECTORS: 2 x RJ45 connectors

MAXIMUM CABLE LENGTH: 100m/328ft on Category 5e cable between device and AVB compliant Ethernet switch

SAMPLE RATE: 48kHz

LATENCY: 0�5ms-2�0ms

COMPATIBLE AVB SWITCHES: BSS Audio/NETGEAR GS724T Ethernet Switch

LABX Titanium 411 Ruggedized AVB Ethernet Bridge Switch
