3
J
D
F
G
I
E
C
H
PRINCIPAL PARTS
(Model PS-57, PS-55, PS-53)
1 BOBBIN WINDER (Page 33)
Winds the thread onto the bobbin to be used for the lower thread.
2 STITCH LENGTH DIAL (Page 15, 26)
Controls the length of the stitches.
3 SPOOL PIN AND SPOOL CAP (Page 33, 39)
4 STITCH WIDTH DIAL (Page 28)
Controls the stitch width.
5 UPPER TENSION CONTROL DIAL (Page 46)
Controls the tension of the upper thread.
6 BUTTONHOLE LEVER (Page 63)
*PS-57, PS-55 only
7 NEEDLE THREADER (Page 41)
8 FLAT BED ATTACHMENT WITH ACCESSORY COMPART-
MENT (Page 14, 32)
9 ZIGZAG PRESSER FOOT (Page 5, 13)
: REVERSE SEWING LEVER (Page 29)
Push for stitching in the reverse direction.
A FEED DOG POSITION SWITCH (Page 30)
B PATTERN INDICATION WINDOW (Page 15)
Shows the stitch number to be performed.
C HOLE FOR VERTICAL SPOOL PIN (Page 44)
Used to hold a second spool of thread for twin needle sewing.
D BALANCE WHEEL
E PATTERN SELECTION DIAL (Page 15)
Turn in either direction to select the desired stitch.
F MAIN POWER/SEWING LIGHT SWITCH (Page 9)
Turn on/off the main power/sewing light switch.
G FOOT CONTROLLER JACK (Page 7)
Insert the foot controller plug for operation and connect the
machine to the power supply.
H BUTTONHOLE FINE ADJUSTMENT SCREW (Page 69)
I PRESSER FOOT LEVER (Page 39)
J FOOT CONTROLLER (Page 10)
Used to control sewing speed/start and stop.
5
2
1
B
3
4
:
A
9
8
7
6
*
TABLE OF CONTENTS
KNOWING YOUR
SEWING MACHINE
STRAIGHT AND
ZIGZAG STITCHING
BUILT-IN STITCHES
BUTTONHOLE AND
BUTTON SEWING
USING ATTACHMENTS
AND APPLICATIONS
MAINTENANCE
INDEX
