31
Use the Setting File Editor to:
● Remove all device-specific settings from the settings file (.json, .dpk, .edpk) at once, or remove only
unnecessary device settings, and save them.
● Create the setting files (.json, .dpk, .edpk) and profiles (.csv) necessary to run the Mapply command.
- Add dynamic (Mapply) keywords to the settings file (.json, .dpk, .edpk) and save them.
- Use an existing profile or create a new profile (.csv) with a field for the dynamic (Mapply) keywords added
to the currently open setting file.
1. Open the Setting File Editor.
- Double-click SettingFileEditor.exe in the “MassDeploymentTool” folder.
OR
Select Open Setting File Editor on the Mass Deployment Tool’s interface.
- When using the Setting File Editor for the first time after installation, launch the Mass Deployment Tool first.
2. To open the settings file, do one of the following:
- Click the File menu and then select Open file.
- Click the Open file button in the center of the screen, and then click the settings file.
- Navigate to the folder with the settings file, and then drag and drop the settings file directly into the
designated area.
3. A dialog box appears, to confirm if you want to remove the device-specific settings.
Click Remove to deselect all the settings listed in the dialog box, if required.
6 Setting File Editor
