CHAPTER 3 PCL5C - 7
(i.e.)
ESC*b#V r, r, r, r, r... Plane 1 1st raster
ESC*b#V g, g, g, g
, g... Plane 2
ESC*b#W b, b, b, b
, b... Plane 3
ESC*b#V r, r, r, r, r... Plane 1 2nd raster
ESC*b#V g, g, g, g, g... Plane 2
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send RGB=(1,1,1)(0,1,1)(1,0,1)(0,0,1)(1,1,0)(0,1,0)(1,0,0)(0,0,0);
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 02h 01h 01h 01h 01h', then select Send Direct Value by Plane.
Select 1 bit/index.
ESC*r1A Start Raster Transfer
ESC*b1V 10101010B Send Plane 1 data (Red data)
ESC*b1V 11001100B Send Plane 2 data (Green data)
ESC*b1W 11110000B Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)
Send Direct Value by Pixel (= 3)
This sends each value of RGB pixel by pixel.
Bits/index must be 8.
(i.e.)
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 1st raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 2nd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 3rd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 4th raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 5th raster
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send the RGB value below;
RGB value.
(0,0,0)(128,128,128)(128,64,0)(255,128,64)
1st raster
(128,128,128)(128,64,0)(255,128,64) (0,0,0) 2nd raster
(128,64,0)(255,128,64) (0,0,0) (128,128,128) 3rd raster
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 03h 08h 08h 08h 08h', then select Send Direct Value by Pixel.
Select 8 bits/index.
ESC*r1A Start Raster Transfer
ESC*b12V 00h 00h 00h 80h 80h 80h 80h 40h 00h ffh 80h 40h Send Plane 1 data (Red data)
ESC*b12V 80h 80h 80h 80h 40h 00h ffh 80h 40h 00h 00h 00h Send Plane 2 data (Green data)
ESC*b12W 80h 40h 00h ffh 80h 40h 00h 00h 00h 80h 80h 80h Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)
