58
APPENDIX
g
Insert the bobbin case so that the
mark on the
bobbin case aligns with the
●
mark on the machine.
• Align the and ● marks.
• Make sure that the indicated points are aligned
before installing the bobbin case.
h
As shown, insert the tab on the needle plate
cover into the hole in the needle plate, and then
correctly position of the needle plate cover.
a Needle plate cover
b Tab
c Hole
• Check that the needle plate cover is flush with
the top surface of the machine.
i
From the front, slide the needle plate cover back
into position.
a Needle plate cover
If the machine stops operating correctly, check the
following possible problems before requesting service.
You can solve most problems by yourself. If you need
additional help, the Brother Solutions Center offers the
latest FAQs and troubleshooting tips. Visit us at “ http://
support.brother.com/ ” .
If the problem persists, contact your dealer or the
nearest authorized service center.
Detailed causes and remedies for common
troubleshooting topics are described below. Be sure to
refer to this before contacting us.
CAUTION
●
Never use a bobbin case that is scratched, otherwise
the upper thread may become tangled, the needle
may break or sewing performance may suffer. For a
new bobbin case (part code: XE7560-001), contact
your nearest authorized service center.
● Make sure that you fit the bobbin case properly,
otherwise the needle may break.
a Bobbin case
b mark
c ● mark
CAUTION
● If the needle plate cover is not flush with the
surface of the machine as shown below, remove
the needle plate cover (step d), and then install
it again (steps
h and i). Sewing while the
needle plate cover is not flush with the surface
of the machine may cause the needle plate
cover to come off of the machine, resulting in
injuries if your fingers touch the race.
TROUBLESHOOTING
Frequent troubleshooting topics
■ Upper thread tightened up page 59
■ Tangled thread on wrong side of
fabric
page 59
■ Incorrect thread tension page 59
■ Fabric is caught in the machine and
cannot be removed
page 60
