ZB80L1
n
ZB110L1 Installation Guide
Page 10
2
1
4
5
6
3
Retrofit Installation
11
Install Knockout Plate, Connect Wires and Reinstall Wiring Panel
Screw from
Parts Bag
Connect wires
Screw set
aside in
Step 6
• Use proper UL-approved connectors to secure wiring to the Knockout Plate provided in Parts Bag.
• Connect wires as shown in wiring diagram.
Attach cable
clamps to
Knockout Plate.
Knockout Plate
mounts to inside of
Housing and may
be oriented
as desired.
LINE
IN
GRD
WHT
BLK
GRD
WHT
WHT
WHT
BLK
BLK BLU
RED
BLK
LIGHT
SWITCH
FAN
SWITCH
FAN
LIGHT
UNITSWITCH BOX
RED
WHT
14/2
14/3
MANUAL
ON
DIMMER
SWITCH
LINE
IN
GRD
WHT
BLK
GRD
WHT
WHT
WHT
BLK
BLK BLU
RED
BLK
MASTER
ON/OFF
SWITCH
FAN
UNIT
SWITCH BOX
RED
WHT
14/2
14/3
FAN
SWITCH
MODE
SELECT
SWITCH
LIGHT
LIGHT WITH ON/OFF SWITCH
LIGHT WITH DIMMER SWITCH
